Airtac SGCJ200-250 Adjustable Cylinder SGCJ200X1000-75
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
AirTAC SGCJ200X1000-75 Adjustable Cylinder Technical Details
- Series: SGCJ200~250 Adjustable Stroke
- Full Model: SGCJ200X1000-75
- Bore Size: 200mm (7.87")
- Stroke: 1000mm adjustable (39.37")
- Mounting: MF1 flange with front trunnion
- Adjustment Type: Mechanical stroke adjustment with locknut
- Operating Pressure: 0.1-1.0 MPa (14.5-145 PSI)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Air cushion + external hydraulic buffer (75mm stroke)
- Body Material: Aluminum alloy with hard anodized finish
- Rod Material: Chrome-plated steel (Cr-Mo alloy)
- Seal Type: NBR seals with wear-resistant guide rings
- Port Size: G1/2 (ISO228 standard)
- Weight: 32.5kg (71.65 lbs) ±2%
-
Dimensions:
- Extended Length: 1485mm (58.46")
- Retracted Length: 485mm (19.09")
- Body Diameter: 250mm (9.84")
- Mounting Flange: 300×300mm (11.81×11.81")
Heavy-duty adjustable stroke cylinder designed for precision positioning in high-mass applications. Features dual cushioning system combining air and hydraulic damping (75mm buffer stroke) for smooth deceleration. The hardened piston rod and triple-lip seals ensure reliable operation in dusty environments. Requires 40μm filtered air with ISO VG32 lubricator oil recommended.
- Automotive press line material handling systems
- Steel coil positioning in rolling mills
- Large-format injection molding machine ejectors
- Paper converting machinery web tension control
- Shipbuilding fixture positioning arms
Installation guidelines:
Maintain 0.1-0.3mm/m alignment tolerance during mounting.
For vertical installations, use rod-down orientation with overload protection.
Perform stroke adjustment only in depressurized state.
| Property | Property Value |
|---|---|
| sku | SGCJ200X1000-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
