Airtac SGCJ200-250 Adjustable Cylinder SGCJ200X120-40S
$493.16
Regular price
$500.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SGCJ200X120-40S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO 15552 (formerly ISO 6431) standard-compliant cylinder;
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
Installation requirements:
Maintain 0.1mm/m alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
during initial setup. Stroke adjustment requires 14mm hex wrench (included). Perform cushion
adjustment at 0.5 MPa pressure during commissioning.
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
AirTAC SGCJ200X120-40S Adjustable Cylinder Specifications
- Model Series: SGCJ200~250 Adjustable Series
- Specific Model: SGCJ200X120-40S
- Bore Size: 200mm
- Stroke: 120mm (adjustable range ±5mm)
- Operating Pressure: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Cushion Type: Adjustable elastic cushion
- Mounting Style: MF (Front flange basic type)
- Port Size: G1/2 (standard), optional NPT1/2
- Piston Rod Material: Hard chrome-plated carbon steel
- Seal Material: High wear-resistant polyurethane (PU)
- Weight: 28.5kg ±2%
- Dimensions (L×W×H):
- Extended Length: 650mm
- Retracted Length: 530mm
- Body Diameter: 250mm
- Mounting Flange: 320×320mm
Heavy-duty adjustable stroke cylinder with precision position locking mechanism. Features double piston seals and chrome-plated piston rod for high cycle durability. Integrated shock absorption system reduces end-impact noise to <75dB. Requires ISO 8573-1:2010 [4:4:3] class compressed air.
Industrial Applications:
- Press machine die height adjustment systems
- Automotive welding fixture positioning
- Steel coil feeding mechanisms
- Injection molding machine ejector units
- Shipbuilding plate bending equipment
Installation requirements:
Maintain 0.1mm/m alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
during initial setup. Stroke adjustment requires 14mm hex wrench (included). Perform cushion
adjustment at 0.5 MPa pressure during commissioning.
Maintenance Cycle:
- Relubrication: Every 500km stroke travel or 6 months
- Seal replacement: 2 million cycles or 2 years
- Rod inspection: Monthly for abrasive environments
| Property | Property Value |
|---|---|
| sku | SGCJ200X120-40S |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 120mm |
