Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X100-100
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ Series Steel Pipe Adjustable Cylinder SGJ125X100-100 Technical Details
- Model Code: SGJ125X100-100
- Bore Size: 125mm (4.92")
- Stroke: 100mm ±1.5mm (3.94")
- Operating Pressure: 0.15-0.8 MPa (21.7-116 PSI)
- Cushion Type: Adjustable rubber bumper (both ends)
- Piston Rod Diameter: 28mm (1.10")
- Rod Thread: M20×1.5
- Mounting Styles: MF1/MF2/MF3 flange, MP4 foot
- Port Size: PT1/2 (NPT1/2 optional)
- Ambient Temperature: -20℃ to 80℃ (-4°F to 176°F)
- Piston Speed: 50-800 mm/s (with cushioning)
- Seal Material: NBR (Nitrile)
- Tube Material: Cold drawn precision steel pipe
- Weight: 5.8 kg (12.79 lbs)
- Dimensions (L×W×H): 350×125×160mm (13.78"×4.92"×6.30")
High-rigidity steel cylinder with enhanced lateral load capacity, featuring dual adjustable cushioning for precise end-position control. The chrome-plated piston rod and anti-corrosion treatment ensure durability in harsh environments. Requires ISO 8573-1:2010 Class 3-4-3 compressed air with 40μm filtration. Lubricated operation recommended (ISO VG32 oil mist).
- Heavy-duty press machine ejection systems
- Automotive welding fixture positioning
- Foundry equipment mold clamping
- Palletizing robot end-effector actuation
- Injection molding machine core-pulling mechanisms
Installation Guidelines:
Align cylinder axis within 0.2mm angular misalignment tolerance.
Use flexible couplings when lateral forces exceed 15% of rated thrust.
Maintain 0.5mm minimum clearance between rod end and load during thermal expansion.
Critical Note:
Avoid side load exceeding 245N·m. For vertical mounting,
always install mechanical lock nuts on rod threads.
Replace cushion seals every 500,000 cycles in high-speed applications.
| Property | Property Value |
|---|---|
| sku | SGJ125X100-100 |
| Adjustable Stroke | 100mm |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 100mm |
