Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X100-20
$244.23
Regular price
$251.73
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SGJ125X100-20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 15552 standard (formerly ISO 6431) for cylinder manufacturing;
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
Installation notes:
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ125X100-20 Steel Tube Adjustable Cylinder Specifications
- Model: SGJ125X100-20
- Type: Double-acting adjustable stroke cylinder (steel tube construction)
- Bore size: 125mm
- Stroke: 100mm (adjustable through cushion mechanism)
- Operating pressure: 0.1–0.9 MPa
- Operating medium: Clean compressed air (lubricated or non-lubricated)
- Ambient temperature: -20℃ to 80℃
- Cushion type: Adjustable pneumatic cushion (both ends)
- Port size: G1/2 (ISO standard thread)
- Piston speed: 50–800 mm/s (with cushion adjustment)
- Mounting type: Standard MF12 square flange
- Rod end thread: M30×1.5
- Weight: 5.8 kg (without accessories)
- Dimensions:
- Total length: 300mm (at mid-stroke position)
- Mounting height: 160mm (flange base to centerline)
- Body diameter: 133mm (tube OD)
- Rod diameter: 28mm
- Seal material: NBR (standard), optional Fluorocarbon for high temp
- Protection class: IP54 (standard wiper seal)
Heavy-duty steel tube cylinder with precision adjustable stroke control, featuring double-wall oxidation-resistant tubing and chromium-plated piston rod. The 20mm thick cushion sleeves allow fine-tuning of end-position deceleration. Includes built-in magnet for position sensing compatibility.
Typical Applications:
- High-cycle press machinery
- Automotive welding fixture positioning
- Foundry equipment material handling
- Heavy conveyor gate control
- Plastic injection molding ejectors
Installation notes:
- Maximum side load capacity: 450N at full extension
- Requires 40μm filtration for optimal seal life
- Lubricator recommended for >500,000 cycle operations
- Allow 15mm clearance for cushion adjustment screws
| Property | Property Value |
|---|---|
| sku | SGJ125X100-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 100mm |
