Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X1000-75
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ Series Steel Tube Adjustable Cylinder SGJ125X1000-75 Technical Details
- Model Code: SGJ125X1000-75
- Type: Steel tube construction with adjustable cushioning
- Bore size: Ø125mm (±0.5mm tolerance)
- Stroke: 1000mm (customizable 50-3000mm)
- Operating pressure: 0.05–0.8 MPa (0.5–8 bar)
- Piston speed: 50–800 mm/s (lubricated condition)
- Ambient temperature: -20℃ to +80℃
- Mounting type: Front flange MF12 (ISO 15552 standard)
- Port size: G3/8 (BSPP thread)
- Seal material: NBR (Nitrile) with wear-resistant guide rings
- Tube material: Cold drawn precision steel (STKM13A)
- Rod material: Chrome-plated steel (JIS S45C)
- Weight: Approximately 24.8 kg (without accessories)
- Dimensions: 1100mm(L) × 160mm(W) × 160mm(H)
- Mounting dimensions: 160mm × 160mm bolt pattern
- Rod end thread: M20×1.5 (male)
- Repeat positioning accuracy: ±0.5mm
Heavy-duty adjustable stroke cylinder featuring anti-corrosion steel construction and precision ground piston rod. The double cushioning design with adjustable buffers (front/rear) enables smooth deceleration, while the multi-lip seal structure ensures 10,000km+ service life under standard operating conditions. Requires ISO VG32 grade lubricant for optimal performance.
- Automotive welding fixture positioning systems
- Sheet metal stamping press ejection mechanisms
- Plastic injection molding machine core pulls
- Heavy conveyor gate actuation
- Industrial press straightening equipment
Installation requirements:
Maintain ≤0.1mm/m alignment tolerance during mounting. Use flexible couplings
for stroke >500mm applications. Lubricate through air supply (oil mist type)
or manual greasing every 3 months. Maximum side load: 150N at full extension.
| Property | Property Value |
|---|---|
| sku | SGJ125X1000-75 |
| Adjustable Stroke | 75mm |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | <1000mm> |
