Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X150-100
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ125X150-100 Steel Pipe Adjustable Cylinder Specifications
- Model: SGJ125X150-100
- Bore size: Ø125mm
- Stroke: 150mm (adjustable)
- Cushion type: Adjustable buffer with locknut
- Operating pressure: 0.15–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: PT1/2 (G1/2 optional)
- Rod end thread: M45x1.5
- Tube material: Cold drawn precision steel pipe (hard chrome plated)
- Piston material: Die-cast aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: ~12.5 kg (without accessories)
- Dimensions: 350mm(L) × 165mm(W) × 165mm(H)
- Mounting style: Basic type (MF1), flange options available
- Protection class: IP54 standard (higher available on request)
Heavy-duty steel cylinder designed for precision linear motion in industrial automation. Features corrosion-resistant chrome plating and dual adjustable pneumatic cushions for smooth deceleration. The reinforced piston rod (hardened steel) withstands side loads up to 30% of maximum thrust. Requires 5-40μm filtered lubricated air (ISO 8573-1).
- Press machine ejection systems
- Automotive welding fixture positioning
- Heavy conveyor gate actuators
- Foundry equipment pusher mechanisms
- Plastic injection molding machine clamps
Installation note:
Allow 0.5-1mm thermal expansion gap during mounting. Lubricate through air port with ISO VG32 hydraulic oil before initial operation. Avoid angular misalignment exceeding ±2°.
| Property | Property Value |
|---|---|
| sku | SGJ125X150-100 |
| Adjustable Stroke | 100mm |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 150mm |
