Airtac SI100 Standard Cylinder SI100X1000SFA
2. Piston sealing adopts reinforced Y-type radial seal structure with compensation capability, featuring extended service life and low dynamic friction;
3. Aerospace-grade aluminum tube with cross-reinforced structure and high-strength tie rods, delivering superior corrosion resistance;
4. Smooth adjustable cushioning mechanism for optimized stroke control;
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
Category: Standard Cylinders , Brand: AIRTAC , Series: SI100
AirTAC SI100X1000SFA Standard Cylinder Specifications
- Model: SI100X1000SFA
- Bore size: 100mm
- Stroke: 1000mm
- Operation type: Double-acting
- Piston rod material: Hard chrome-plated steel
- Cylinder tube: Aluminum alloy with oxidation-resistant coating
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Basic type (MF1)
- Port size: G3/8
- Seal material: NBR (Nitrile rubber)
- Weight: 12.8kg ±2%
- Dimensions:
- Extended length: 1325mm
- Retracted length: 325mm
- Body diameter: 128mm
High-load industrial cylinder designed for long-stroke applications requiring precise linear motion. Features wear-resistant rod guides and integrated magnetic sensor slots (compatible with most industry-standard proximity switches). The heavy-duty construction withstands side loads up to 15% of maximum thrust capacity.
- Automotive assembly line lifting mechanisms
- Steel coil handling equipment
- Injection molding machine ejectors
- Large-format CNC machine tool positioning
- Industrial press feeding systems
Installation note:
Requires alignment tolerance ≤0.2mm/m to prevent rod binding. For vertical mounting,
use guided carriage systems. Lubricate with ISO VG32 hydraulic oil if operated below 0.3 MPa.
| Property | Property Value |
|---|---|
| sku | SI100X1000SFA |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
