Airtac SI125 Standard Cylinder SI125X1000SCB
2. Piston features bidirectional Y-seal structure with cushioning function, offering extended service life and low friction resistance;
3. Aluminum barrel with cruciform reinforcement and black-anodized piston rod for enhanced corrosion resistance;
4. Precision machined cylinder surface ensures smooth operation;
5. Multiple cylinder specifications and mounting accessories available for flexible configurations.
Category: Standard Cylinders | Brand: AIRTAC | Series: SI125
AirTAC SI125X1000SCB Standard Cylinder Specifications
- Model: SI125X1000SCB
- Bore size: 125 mm (4.92")
- Stroke: 1000 mm (39.37")
- Operating pressure: 0.05–1.0 MPa (7-145 psi)
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: SCB series - Double pivot bracket
- Port size: G1/2 (ISO standard)
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Operating temperature: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 28.5 kg (62.8 lbs)
- Dimensions (L×W×H):
- Retracted length: 1180 mm (46.46")
- Extended length: 2180 mm (85.83")
- Body diameter: 136 mm (5.35")
- Mounting bracket width: 180 mm (7.09")
- Rod end thread: M20×1.5
- Lubrication: Pre-lubricated (Daphne AL-2 grease)
- ISO standard: 15552 compliant
High-force industrial cylinder designed for heavy-duty linear motion applications. Features precision honed tube and multi-lip seals for leak-free operation. The SCB mounting configuration provides enhanced stability for long-stroke applications. Includes magnetic sensor slots (model suffix "-M" for switch-ready versions).
- Press machine ejection systems
- Automotive assembly line positioning
- Steel mill material handling gates
- Plastic injection molding machine clamps
- Paper processing equipment actuators
Installation note:
Support rod at mid-span for strokes >800mm. Align mounting brackets within
0.2mm/mm parallelism tolerance. Use flexible couplings to prevent side load.
| Property | Property Value |
|---|---|
| sku | SI125X1000SCB |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | <1000mm> |
