Airtac SI160 Standard Cylinder SI160X1000
2. NBR Y-shaped piston sealing structure with integrated cushioning mechanism, featuring long service life and low friction coefficient
3. Precision-milled aluminum tube with black-hardened piston rod for enhanced corrosion resistance
4. Smooth operation with adjustable cushioning mechanism
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible system integration
Category: Standard Cylinders , Brand: AIRTAC , Series: SI160
AirTAC SI160X1000 Standard Cylinder Specifications
- Model: SI160X1000
- Bore size: 160mm
- Stroke: 1000mm
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Adjustable air cushion (both ends)
- Port size: G1" (Rc1" optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Mounting type: Basic (MF1), Front flange (MF2), Rear flange (MF3), Foot mounting (MP4)
- Material: Aluminum alloy barrel, hardened steel piston rod
- Seal material: NBR/PU (standard), optional FKM for high temp
- Rod end type: External thread (M30x2)
- Protection rating: IP65 (standard), IP67 optional
- Weight: Approximately 34.5 kg (dry)
- Dimensions: 1345mm(L) x 180mm(W) x 180mm(H)
High-thrust industrial cylinder designed for heavy-duty linear motion applications. Features precision honed tube with hard chrome-plated piston rod for extended service life. The extended 1000mm stroke version requires additional lateral support in vertical installations. Compatible with ISO 15552 mounting accessories.
- Metal stamping press ejection systems
- Automotive assembly line positioning
- Paper roll handling equipment
- Injection molding machine clamp opening
- Shipbuilding fixture actuators
Installation note:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended).
For vertical mounting over 500mm stroke, use guided carriage or rod support brackets.
Allow ±0.5mm alignment tolerance during installation.
| Property | Property Value |
|---|---|
| sku | SI160X1000 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | 160mm |
| Stroke | <1000mm> |
