Airtac SI160 Standard Cylinder SI160X1000FTC
2. NBR Y-shaped piston sealing structure with integrated cushioning mechanism, featuring long service life and low friction coefficient
3. Precision-milled aluminum tube with black-hardened piston rod for enhanced corrosion resistance
4. Smooth operation with adjustable cushioning mechanism
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible system integration
Category: Standard Cylinders , Brand: AIRTAC , Series: SI160
AirTAC SI160X1000FTC Standard Cylinder Specifications
- Model: SI160X1000FTC
- Type: ISO 15552 compliant double-acting pneumatic cylinder
- Bore size: 160mm
- Stroke: 1000mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Front flange (MF1) with integrated mounting holes
- Port size: G1/2 (NPT1/2 optional)
- Temperature range: -20℃ to 80℃
- Body material: Aluminum alloy (anodized surface)
- Seal material: NBR/PU compound (oil/moisture resistant)
- Rod material: Chrome-plated steel (H5 precision)
- Weight: 23.5 kg (±2%)
- Dimensions: 1295mm(L) × 180mm(W) × 180mm(H)
- Piston rod diameter: 45mm
- Max theoretical force (@0.63MPa): 12,700N (extend), 11,200N (retract)
- ISO speed range: 50–800 mm/s
- Protection rating: IP65 (rod seal)
High-capacity industrial cylinder optimized for heavy-load linear motion. Features precision honed tube (Ra≤0.2μm) and dual anti-rotation guides for exceptional stability in long-stroke applications. Built-in magnet (T-suffix) enables position feedback when paired with sensors. Pre-lubricated for 2000km service life under standard conditions.
- Injection molding machine ejectors
- Steel coil handling systems
- Automotive assembly line positioning
- Paper roll clamping mechanisms
- Shipbuilding plate pressing equipment
Installation guidelines:
Use alignment jigs during mounting to prevent side load. Maintain 0.5–1mm/m parallel tolerance.
For vertical installations, add mechanical brake unit (sold separately). Lubricate through port
with ISO VG32 oil every 50km of operation.
| Property | Property Value |
|---|---|
| sku | SI160X1000FTC |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | 160mm |
| Stroke | <1000mm> |
