Airtac SI160 Standard Cylinder SI160X100S
2. NBR Y-shaped piston sealing structure with integrated cushioning mechanism, featuring long service life and low friction coefficient
3. Precision-milled aluminum tube with black-hardened piston rod for enhanced corrosion resistance
4. Smooth operation with adjustable cushioning mechanism
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible system integration
Category: Standard Cylinders , Brand: AIRTAC , Series: SI160
AirTAC SI160X100S Standard Cylinder Specifications
- Model: SI160X100S
- Bore size: 160mm
- Stroke: 100mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Mounting style: Basic type (Standard MF1 flange)
- Port size: G1/2 (NPT1/2 optional)
- Operating temperature: -20℃ to 80℃
- Cylinder material: Aluminum alloy (hard anodized)
- Piston rod material: Chrome-plated steel (Cr-Mo steel)
- Seal type: NBR + PU combination seals
- Weight: 8.7kg (bare cylinder), 9.2kg (with accessories
- Dimensions: 332mm(L) × 176mm(W) × 176mm(H)
- Max thrust: 12,566N @0.5MPa
- Max speed: 500mm/s
- Protection rating: IP65 (rod extension area IP54)
High-power industrial cylinder with dual-piston design for heavy load applications. Features wear-resistant rod scraping ring and anti-rotation mechanism. The triple-lip seal structure ensures minimal leakage even under low-lubrication conditions. Compatible with ISO 15552 mounting accessories.
- Injection molding machine clamp mechanisms
- Steel coil handling systems
- Automotive welding fixture positioning
- Paper roll pressing equipment
- Shipbuilding jig actuators
Installation note:
Maintain 0.5°-1° downward tilt when horizontal mounting to ensure proper lubrication retention.
Requires 20μm filtered air with ISO 8573-1:2010 Class 4-4-3 quality. Lubricator recommended for >1 million cycle operations.
| Property | Property Value |
|---|---|
| sku | SI160X100S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 160mm |
| Stroke | 100mm |
