Airtac SI160 Standard Cylinder SI160X1030
2. NBR Y-shaped piston sealing structure with integrated cushioning mechanism, featuring long service life and low friction coefficient
3. Precision-milled aluminum tube with black-hardened piston rod for enhanced corrosion resistance
4. Smooth operation with adjustable cushioning mechanism
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible system integration
Category: Standard Cylinders , Brand: AIRTAC , Series: SI160
AirTAC SI160X1030 Standard Cylinder Technical Specifications
- Model: SI160X1030
- Series: SI standard cylinder ISO 15552 compliant
- Bore size: 160mm
- Stroke: 1030mm
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G3/8 (NPT1/2 optional)
- Operating temperature: -20℃ to 80℃
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Mounting types: Basic series (MF1), front flange (MF2), rear flange (MF3), foot mounting (MF4)
- Weight: Approximately 3.8kg (without rod) / 15.2kg (assembled)
- Dimensions:
- Body diameter: 160mm
- Total length: 1090mm (base length 60mm + stroke)
- Rod end thread: M33×2.0
- Rod diameter: 45mm
- Protection rating: IP54 (standard) / IP67 (optional wiper upgrade)
- Lubrication: Pre-lubricated (non-re-lube design)
A heavy-duty industrial cylinder designed for long-stroke applications requiring consistent force output. Features dual adjustable cushions for smooth deceleration and impact reduction at stroke ends. The anodized surface treatment provides enhanced corrosion resistance in humid environments. Optional magnetic piston version (SI160X1030-M9) available for position sensing.
- Automotive assembly line clamping fixtures
- Plastic injection molding machine ejectors
- Steel mill material handling systems
- Paper processing equipment actuators
- Shipbuilding jig positioning mechanisms
Installation note:
When mounting vertically, use MF2/MF3 flange types with locknuts. For strokes over 800mm,
recommend adding intermediate support brackets every 500mm to prevent rod deflection.
Maintain 0.3-1.0 MPa lubrication pressure during initial operation.
| Property | Property Value |
|---|---|
| sku | SI160X1030 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | 160mm |
| Stroke | 1030mm |
