Airtac SI160 Standard Cylinder SI160X1050
2. NBR Y-shaped piston sealing structure with integrated cushioning mechanism, featuring long service life and low friction coefficient
3. Precision-milled aluminum tube with black-hardened piston rod for enhanced corrosion resistance
4. Smooth operation with adjustable cushioning mechanism
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible system integration
Category: Standard Cylinders , Brand: AIRTAC , Series: SI160
AirTAC SI160X1050 Standard Cylinder Specifications
- Model: SI160X1050
- Type: ISO 15552 compliant standard cylinder
- Bore size: 160 mm
- Stroke: 1050 mm
- Operating pressure: 0.1–1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Port size: G3/4 (ISO 228/1 standard)
- Piston rod thread: M20×1.5 (external)
- Tube material: Anodized aluminum alloy
- Rod material: Hard chrome-plated steel
- Seal material: NBR/PU compound
- Temperature range: -20℃ to 80℃
- Weight: 28.5 kg (±2%)
- Dimensions (L×W×H):
- Retracted length: 1,320 mm
- Extended length: 2,370 mm
- Body width: 190 mm
- Mounting height: 230 mm
- Mounting options: Basic type (with foot mounting)
- Corrosion resistance: Class II (ISO 9227)
High-capacity industrial cylinder designed for heavy-duty linear motion applications requiring extended stroke precision. Features triple sealing system with wiper, primary seal, and buffer seal for contamination resistance. The oversized rod design (28mm diameter) ensures stability during full extension.
- Automotive press line material handling
- Steel coil feeding mechanisms
- Injection molding machine ejectors
- Large-scale packaging systems
- Paper mill roller positioning
Installation note:
Requires rigid mounting surface with flatness ≤0.1mm/m. For vertical installations,
use rod-end support brackets when stroke exceeds 800mm. Lubricate through air supply
(ISO VG32 equivalent oil mist) for optimal seal performance.
| Property | Property Value |
|---|---|
| sku | SI160X1050 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | 160mm |
| Stroke | 1050mm |
