Airtac SI160 Standard Cylinder SI160X1100
2. NBR Y-shaped piston sealing structure with integrated cushioning mechanism, featuring long service life and low friction coefficient
3. Precision-milled aluminum tube with black-hardened piston rod for enhanced corrosion resistance
4. Smooth operation with adjustable cushioning mechanism
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible system integration
Category: Standard Cylinders , Brand: AIRTAC , Series: SI160
AirTAC SI160X1100 Standard Cylinder Specifications
- Model: SI160X1100
- Type: ISO 15552 compliant double-acting cylinder
- Bore size: 160 mm
- Stroke: 1100 mm
- Operating pressure: 0.1–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: 1/2" NPT (G1/2 optional)
- Piston rod diameter: 28 mm (chromed steel)
- Seal material: Nitrile (NBR) with wear-resistant band
- Temperature range: -20℃ to 80℃
- Weight: 23.5 kg (without accessories)
- Dimensions: 1395mm(L) × 180mm(W) × 180mm(H)
- Rod thread: M20×1.5
- Max theoretical force: 2010 N @ 0.63 MPa
- Lubrication: Pre-lubricated (oil-free operation possible)
- Mounting: Standard ISO 15552 mounts (front flange, rear foot, etc.)
High-force industrial cylinder designed for heavy-duty linear motion applications. Features corrosion-resistant aluminum barrel with stainless steel end caps and precision honed inner surface (Ra ≤0.2μm). The magnetic piston version (SI160MX1100) enables position sensing compatibility. Built-in shock absorbers minimize end-impact noise at maximum stroke velocity (≤1.5 m/s).
- Automotive assembly line clamping systems
- Steel mill material handling actuators
- Plastic injection molding ejectors
- Paper processing machinery
- Heavy-duty press brake tooling
Installation note:
Maintain 0.1-0.3mm alignment tolerance during mounting. For vertical installations exceeding 45° angle,
use auxiliary rod support brackets. Lubricate every 500km of cumulative travel distance under normal loads.
| Property | Property Value |
|---|---|
| sku | SI160X1100 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | 160mm |
| Stroke | 1100mm |
