Airtac SI200 Standard Cylinder SI200X1000S
2. Piston seal employs Y-type radial sealing structure with self-lubricating feature, offering extended service life and low friction resistance;
3. Aluminum alloy tube with reinforced rib design, black hard chrome-plated piston rod for superior corrosion resistance;
4. Cylinder barrel features smooth anodized surface treatment with excellent wear resistance;
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible configuration.
Category: Standard Cylinders, Brand: AirTAC, Series: SI200
AirTAC SI200X1000S Standard Cylinder Specifications
- Model: SI200X1000S
- Type: ISO 15552 compliant double-acting cylinder
- Bore size: 200 mm
- Stroke: 1000 mm
- Operating pressure: 0.05–1.2 MPa
- Cushion type: Adjustable pneumatic cushion (both ends)
- Mounting style: Standard ISO mounting (multiple options: FB, MP4, etc.)
- Port size: G3/8 (NPT1/2 optional)
- Piston rod diameter: 45 mm (chrome-plated steel)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Weight: ~34.5 kg (without accessories)
- Dimensions (L×W×H):
- Retracted length: 1210 mm ±5 mm
- Extended length: 2210 mm ±5 mm
- Width (mounting face): 75 mm
- Height (including rod): 260 mm
- Rod thread: M45×1.5
- Maximum theoretical force:
- Thrust @0.6MPa: 18,850 N
- Pull force @0.6MPa: 16,340 N
- ISO standard: 15552 (formerly ISO 6431/DIN ISO 6432)
High-load industrial cylinder designed for heavy-duty automation applications. Features precision honed tube with wear-resistant coating and multi-layered sealing system. Integrated magnetic piston enables position sensing compatibility. Cushioning adjustment allows fine-tuning of end-stroke deceleration.
- Automotive production line clamping systems
- Steel coil handling equipment
- Injection molding machine ejectors
- Paper mill roller positioning
- Heavy material press operations
Installation note:
Requires proper alignment with guided carriage systems for strokes >500mm.
Lubrication: Initial grease filling (VG68) required, maintenance interval
every 2,000 km of cumulative travel.
Critical parameters:
Maximum allowable side load: 1,250 N at mid-stroke.
Do not exceed 0.8 m/s piston speed without external shock absorbers.
| Property | Property Value |
|---|---|
| sku | SI200X1000S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
