Airtac SI200 Standard Cylinder SI200X100H
2. Piston seal employs Y-type radial sealing structure with self-lubricating feature, offering extended service life and low friction resistance;
3. Aluminum alloy tube with reinforced rib design, black hard chrome-plated piston rod for superior corrosion resistance;
4. Cylinder barrel features smooth anodized surface treatment with excellent wear resistance;
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible configuration.
Category: Standard Cylinders, Brand: AirTAC, Series: SI200
AirTAC SI200X100H Standard Cylinder Specifications
- Model: SI200X100H
- Bore size: 200mm
- Stroke: 100mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Mounting type: Basic type (MF1), optional flange/feet mounting
- Port size: G3/8 (1/2" NPT optional)
- Operating temperature: -20℃ to 80℃
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated steel (STD) or stainless steel (optional)
- End caps: Aluminum alloy
- Seal material: NBR/PU (standard), FKM available for high-temp
- Weight: 15.8kg (with standard accessories)
- Dimensions:
- Total length (extended): 445mm
- Body diameter: 220mm
- Mounting base width: 180mm
- Rod end thread: M20×1.5
- ISO standard: 15552 compliant
High-force industrial cylinder with precision-machined components for heavy-duty applications. Features double-acting operation, corrosion-resistant construction, and customizable mounting options. The hard-chromed piston rod provides exceptional wear resistance, while the magnetic piston version (SI200X100H-M9) enables position sensing.
- Press machine clamping mechanisms
- Automotive assembly line positioning
- Plastic injection molding ejectors
- Steel mill material handling systems
- Packaging equipment compression units
Installation note:
Maintain 0.05-0.15mm clearance between rod and guide during alignment.
Lubricate with ISO VG32 hydraulic oil if using non-lubricated air.
Adjust cushion needles gradually (1/4 turns) for optimal deceleration.
| Property | Property Value |
|---|---|
| sku | SI200X100H |
| Seal Material | FKM |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
