Airtac SI200 Standard Cylinder SI200X1100
2. Piston seal employs Y-type radial sealing structure with self-lubricating feature, offering extended service life and low friction resistance;
3. Aluminum alloy tube with reinforced rib design, black hard chrome-plated piston rod for superior corrosion resistance;
4. Cylinder barrel features smooth anodized surface treatment with excellent wear resistance;
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible configuration.
Category: Standard Cylinders, Brand: AirTAC, Series: SI200
AirTAC SI200X1100 Standard Cylinder Technical Specifications
- Model: SI200X1100
- Bore size: Ø200 mm
- Stroke: 1100 mm
- Operating pressure: 0.05–1.0 MPa
- Medium temperature: -20℃ to 80℃
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Piston rod thread: M30×2.0 (standard)
- Port size: G3/8 (NPT1/2 optional)
- Mounting type: Basic type (MF1) with optional flange/clevis mounts
- Rod end type: Female thread (external rod rotation prevention standard)
- Seal material: Nitrile rubber (NBR) with wear-resistant ring
- Tube material: Anodized aluminum alloy
- Weight: 53.6 kg (±2%)
- Dimensions: 1375mm(L) × 220mm(W) × 220mm(H)
- Max theoretical thrust: 3140N @0.5MPa
- Speed range: 50–800 mm/s (lubricated)
- ISO standard: 15552 compliant
High-power industrial cylinder optimized for heavy-duty linear motion applications. Features double-acting operation with corrosion-resistant aluminum construction and precision honed tube. Integrated magnetic piston allows position sensing compatibility (sensor not included). Requires ISO VG32 or equivalent hydraulic oil lubrication for optimal seal performance.
- Metal stamping press ejection systems
- Automotive assembly line clamping devices
- Injection molding machine core-pulling mechanisms
- Large-scale material handling gates/doors
- Heavy-duty wood processing machinery
Installation guidelines:
Maintain horizontal mounting orientation for full-stroke operations.
Allow minimum 30mm clearance around cylinder body for heat dissipation.
Use flexible couplings for stroke >800mm applications to prevent side load.
- Relubricate every 500km of cumulative travel
- Inspect rod seals every 1 million cycles
- Replace cushion seals every 3 years under normal operation
| Property | Property Value |
|---|---|
| sku | SI200X1100 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 1100mm |
