Airtac SI200 Standard Cylinder SI200X1175
2. Piston seal employs Y-type radial sealing structure with self-lubricating feature, offering extended service life and low friction resistance;
3. Aluminum alloy tube with reinforced rib design, black hard chrome-plated piston rod for superior corrosion resistance;
4. Cylinder barrel features smooth anodized surface treatment with excellent wear resistance;
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible configuration.
Category: Standard Cylinders, Brand: AirTAC, Series: SI200
AirTAC SI200X1175 Standard Cylinder Specifications
- Model: SI200X1175
- Bore size: Ø200 mm
- Stroke: 1175 mm
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Basic foot mounting (MF1) with optional alternatives: LB, MP4, or MP6
- Port size: G3/8 (alternative NPT1/2 available)
- Piston speed: 50–800 mm/s (lubricated condition)
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Material:
- Cylinder tube: Aluminum alloy hard anodized
- Piston rod: Chrome-plated steel (STS303 equivalent)
- Seals: NBR + Polyurethane combination
- Weight: 23.8 kg (52.5 lbs) ±2%
- Dimensions:
- Total length: 1375 mm (stroke + 200mm end structures)
- Body diameter: 220 mm (including mounting flanges)
- Foot mounting base: 250mm × 180mm × 25mm
- Protection rating: IP65 (standard wiper seal configuration)
- Air consumption: 9.42 L/cycle @ 0.5 MPa
High-force industrial cylinder designed for heavy-duty linear motion applications. Features double-acting operation with precision-machined guide bands for minimal lateral deflection. The triple-seal design combines dust lip, primary seal, and lubricating wiper for extended service life in particulate-heavy environments. Requires ISO 8573-1:2010 Class 3-4-3 compressed air quality.
- Metal stamping press ejection systems
- Automotive welding fixture positioning
- Paper roll handling in converting machinery
- Injection molding machine core pullers
- Shipbuilding plate bending apparatus
Installation protocol:
Requires torque-controlled mounting (22-25 N·m for foot bolts).
Must maintain 0.5-1mm thermal expansion gap between cylinder
and machine frame. Lubricator unit recommended for cycles
exceeding 50,000/month.
| Property | Property Value |
|---|---|
| sku | SI200X1175 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 1175mm |
