Airtac SI200 Standard Cylinder SI200X1200
2. Piston seal employs Y-type radial sealing structure with self-lubricating feature, offering extended service life and low friction resistance;
3. Aluminum alloy tube with reinforced rib design, black hard chrome-plated piston rod for superior corrosion resistance;
4. Cylinder barrel features smooth anodized surface treatment with excellent wear resistance;
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible configuration.
Category: Standard Cylinders, Brand: AirTAC, Series: SI200
AirTAC SI200X1200 Standard Cylinder Specifications
- Model: SI200X1200
- Type: ISO 15552 compliant single-acting/double-acting cylinder
- Bore size: Ø200 mm
- Stroke: 1200 mm
- Operating pressure: 0.05–1.2 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Basic type (male thread) / Optional flange/clevis mounts
- Port size: G3/4 (ISO 228 standard)
- Piston rod diameter: Ø45 mm (chrome-plated steel)
- Cylinder tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber) standard / Optional FKM
- Lubrication: Pre-lubricated (Oil-free operation possible)
- Weight: 43.6 kg (dry, without accessories)
- Dimensions (L×W×H):
- Body length: 325 mm (excluding rod)
- Total extended length: 1525 mm (at 1200mm stroke)
- External diameter: 210 mm
- Mounting base height: 25 mm
High-force industrial cylinder designed for heavy-duty linear motion applications. Features corrosion-resistant construction with double-sealed piston for reliable operation in harsh environments. The reinforced rod design minimizes deflection during full-stroke extension. Requires 40μm filtered air and optional magnetic piston for position sensing.
- Automotive press line material handling
- Steel mill door actuators
- Plastic injection molding ejectors
- Shipbuilding positioning systems
- Hydraulic press assist systems
Installation note:
For strokes over 1000mm, recommend using intermediate rod support brackets.
Maintain 0.5-1mm alignment tolerance during mounting. Lubricate rod weekly in
high-cycled applications (＞500 cycles/day).
| Property | Property Value |
|---|---|
| sku | SI200X1200 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 1200mm |
