Airtac SI32 Standard Air Cylinder SI32X1000
2. Piston features dual Y-shaped bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Corrosion-resistant tie rods with reinforced crisscross tubing structure;
4. Smooth cylinder operation with adjustable cushioning;
5. Multiple cylinder specifications and optional mounting accessories available for customized configurations.
Category: Standard Cylinders, Brand: AIRTAC, Series: SI32
AirTAC SI32X1000 Standard Cylinder Technical Details
- Bore size: 32mm (ISO 6432 standard)
- Stroke: 1000mm (extendable to 1500mm with customization)
- Operating pressure: 0.15–0.8 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Port size: 1/4" NPT (G1/8 optional)
- Piston rod diameter: 12mm (chrome-plated steel)
- Maximum thrust: 206N @0.6MPa (push/pull force varies by pressure)
- Operating temperature: -20℃ to 80℃
- Ambient humidity: ≤95% RH (non-condensing)
- Weight: 4.35kg (excluding mounting accessories)
- Dimensions: 1100mm(L) × 50mm(W) × 50mm(H) (retracted length)
- Material: Aluminum alloy barrel, carbon steel end caps
- Seal type: NBR seals (Viton available for high-temp versions)
- Mounting options: MF1 (front flange), MP2 (rear pivot), MY1 (axial foot)
- Protection class: IP40 (standard), IP67 with optional wiper seal
- Lubrication: Pre-lubricated (use ISO VG32 pneumatic oil if required)
High-precision long-stroke cylinder featuring dual adjustable pneumatic cushions for smooth deceleration. The hard-anodized barrel resists scoring and corrosion, while the triple-lip rod seal ensures minimal leakage. Requires filtered air (5-50μm) with 1-10ppm oil mist content. Special anti-rotation design maintains alignment in vertical installations.
- Automated palletizing systems (box pushing/positioning)
- Plastic injection molding machine ejectors
- Automotive assembly line clamping fixtures
- Textile machinery thread tension control
- Solar panel cleaning robot actuators
Installation guidelines:
For horizontal mounting exceeding 800mm stroke, use mid-support brackets (ASM32 accessory recommended).
Adjust cushion needles gradually - overtightening may cause piston deformation. Allow 20mm clearance
behind end covers for maintenance access.
| Property | Property Value |
|---|---|
| sku | SI32X1000 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | <1000mm> |
