Airtac SI32 Standard Air Cylinder SI32X100STC
2. Piston features dual Y-shaped bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Corrosion-resistant tie rods with reinforced crisscross tubing structure;
4. Smooth cylinder operation with adjustable cushioning;
5. Multiple cylinder specifications and optional mounting accessories available for customized configurations.
Category: Standard Cylinders, Brand: AIRTAC, Series: SI32
AirTAC SI32X100STC Standard Cylinder Specifications
- Model: SI32X100STC
- Bore size: 32mm
- Stroke: 100mm
- Action type: Double-acting
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Cushioning type: Adjustable cushioning (both ends)
- Mounting style: Basic mounting (standard)
- Port size: PT1/4 (G1/8 optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated steel
- Seals: NBR (Nitrile rubber)
- Weight: 1.25kg (without accessories)
- Dimensions:
- Extended length: 228mm
- Retracted length: 128mm
- Body diameter: 32mm
- Mounting base: 32×32mm square pattern
- Protection class: IP65
- Lubrication: Pre-lubricated (relubrication required every 2000km)
A high-precision ISO 6432 compliant cylinder featuring corrosion-resistant construction and energy-efficient operation. The dual adjustable cushions minimize end-impact noise while allowing precise stroke adjustment. Special rod seal design reduces breakaway pressure to <0.08MPa. Compatible with all standard AirTAC mounting accessories.
- Packaging machinery clamping devices
- Automotive assembly line positioning systems
- Conveyor belt material pushers
- Food processing equipment actuators
- CNC machine tool jig fixtures
Installation notes:1. Maintain 0.5mm minimum clearance between rod end and load during alignment
2. Use M5 mounting screws with 3.5Nm torque limit
3. For vertical mounting: Add 10% extra thrust capacity margin
4. Lubricate through air port using ISO VG32 turbine oil only
Requires 5μm filtered compressed air with dew point ≥3℃ below ambient temperature. Not suitable for vacuum applications.
| Property | Property Value |
|---|---|
| sku | SI32X100STC |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
