Airtac SI32 Standard Air Cylinder SI32X1050S
2. Piston features dual Y-shaped bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Corrosion-resistant tie rods with reinforced crisscross tubing structure;
4. Smooth cylinder operation with adjustable cushioning;
5. Multiple cylinder specifications and optional mounting accessories available for customized configurations.
Category: Standard Cylinders, Brand: AIRTAC, Series: SI32
AirTAC SI32X1050S Standard Cylinder Specifications
- Model: SI32X1050S
- Type: ISO 6432 compliant double-acting cylinder
- Bore size: 32 mm
- Stroke: 1050 mm (max extended length)
- Operating pressure: 0.05–0.9 MPa
- Cushioning type: Adjustable buffer at both ends
- Piston rod thread: M14×1.5
- Temperature range: -20℃ to 80℃
- Seal material: NBR/PU compound seals
- Port size: G1/4 (ISO 228-1 standard)
- Mounting options: Basic type (no foot), MF1 front flange, MB1 rear flange
- Weight: 3.85 kg (without accessories)
- Dimensions (retracted): 1,180 mm(L) × 42 mm(W) × 42 mm(H)
- Max theoretical force: 723 N @ 0.7 MPa
- Piston speed: 50–800 mm/s
- Sensor compatibility: Built-in magnet for proximity switches (D-A93 series)
High-precision industrial cylinder engineered for long-stroke applications requiring exceptional straight-line stability. Features chromium-plated piston rod with integrated scraper ring to prevent contamination. The anodized aluminum barrel ensures corrosion resistance in humid environments.
- Automated assembly line material transfer systems
- Packaging machinery ejection mechanisms
- Automotive welding fixture positioning
- Large-format CNC machine tool clamps
- Solar panel production line handling
Installation guidelines:
Requires lateral support when stroke exceeds 800mm. Use alignment jigs during
mounting to prevent rod deflection. Lubricate with ISO VG32 hydraulic oil
during maintenance cycles. Avoid rapid pressure changes >0.3 MPa/ms.
| Property | Property Value |
|---|---|
| sku | SI32X1050S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 1050mm |
