Airtac SI32 Standard Air Cylinder SI32X105S
2. Piston features dual Y-shaped bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Corrosion-resistant tie rods with reinforced crisscross tubing structure;
4. Smooth cylinder operation with adjustable cushioning;
5. Multiple cylinder specifications and optional mounting accessories available for customized configurations.
Category: Standard Cylinders, Brand: AIRTAC, Series: SI32
AirTAC SI32X105S Standard Cylinder Specifications
- Model: SI32X105S
- Bore size: 32 mm
- Stroke: 105 mm
- Operating pressure: 0.05–0.9 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Port size: M5×0.8 (G1/8 optional)
- Rod thread: M10×1.25
- Seal material: NBR (Nitrile Butadiene Rubber)
- Mounting type: Basic front flange (ISO 15552 standard)
- Protection rating: IP54 (standard wiper design)
- Weight: 1.42 kg (without accessories)
- Dimensions:
- Body length: 186 mm (minimum retracted length)
- Extended length: 186 + 105 = 291 mm
- Width (square body): 42 mm
- Height (including rod): 60 mm (retracted)
High-precision ISO 15552 compliant cylinder featuring anodized aluminum construction with chromed piston rod. The SI32X105S combines medium load capacity (1,080N thrust at 0.6MPa) with optimized air consumption. Includes built-in magnetic sensor slots (Reed switch compatible) for position feedback. Requires 40μm filtered lubricated air (ISO 8573-1 class 4) for optimal performance.
- Automated assembly line part positioning
- Packaging machine clamp actuation
- CNC machine tool door interlocks
- Plastic injection molding ejector systems
- Material handling transfer units
Installation note:
Lubricate through air supply (ISO VG32 turbine oil recommended).
Allow ≥10mm lateral clearance for sensor mounting.
Maximum side load: 25N at full extension.
For vertical mounting, use guide brackets to prevent piston rod deflection.
| Property | Property Value |
|---|---|
| sku | SI32X105S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 105mm |
