Airtac SI32 Standard Air Cylinder SI32X110
2. Piston features dual Y-shaped bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Corrosion-resistant tie rods with reinforced crisscross tubing structure;
4. Smooth cylinder operation with adjustable cushioning;
5. Multiple cylinder specifications and optional mounting accessories available for customized configurations.
Category: Standard Cylinders, Brand: AIRTAC, Series: SI32
AirTAC SI32X110 Standard Cylinder Specifications
- Model: SI32X110
- Bore size: 32 mm
- Stroke: 110 mm
- Operating pressure: 0.15–0.9 MPa
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Basic type (MF1), optional front flange (MP4) or rear flange (MP5)
- Port size: 1/4" NPT (G1/8 optional)
- Piston rod thread: M10×1.25
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Piston speed: 50–800 mm/s
- Weight: 1.2 kg (bare cylinder)
- Dimensions: 230mm(L) × 48mm(W) × 48mm(H) (at mid-stroke position)
- Rod end type: Female thread + hex nut
- Optional accessories: Magnetic sensor (D-A93), rod lock kit
High-precision ISO 15552 compliant cylinder with dual cushioning adjustment and corrosion-resistant aluminum alloy construction. Features wear-resistant bronze guide bushings and integrated mounting slots for flexible installation. Requires 40μm filtered air with ISO 8573-1:2010 class 4.4.3 cleanliness standards.
- Automated assembly line clamping mechanisms
- Plastic injection molding ejector systems
- CNC machine tool door actuators
- Food processing conveyor gate controls
- Automotive welding fixture positioning
Installation note:
Lubricate rod with ISO VG32 hydraulic oil before initial operation.
Maintain 0.5mm minimum parallel alignment tolerance during mounting.
For vertical installations, use locknut (SWM10-45) to prevent rod rotation.
- Theoretical thrust: 483 N (advancing)
- Theoretical pull force: 456 N (retracting)
- Minimum effective force: 420 N (considering 85% efficiency factor)
| Property | Property Value |
|---|---|
| sku | SI32X110 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 110mm |
