Airtac SI32 Standard Air Cylinder SI32X110FA
2. Piston features dual Y-shaped bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Corrosion-resistant tie rods with reinforced crisscross tubing structure;
4. Smooth cylinder operation with adjustable cushioning;
5. Multiple cylinder specifications and optional mounting accessories available for customized configurations.
Category: Standard Cylinders, Brand: AIRTAC, Series: SI32
AirTAC SI32X110FA Standard Cylinder Specifications
- Model: SI32X110FA
- Bore size: 32mm
- Stroke: 110mm
- Operation: Double-acting
- Working pressure: 0.05–1.0 MPa
- Cushioning: Adjustable cushioning (both ends)
- Mounting type: Basic type (foot-mounted) with multiple mounting options available
- Port size: M5x0.8 (Standard) / NPT1/8 optional
- Piston rod thread: M12x1.25
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP40 (Dust-proof)
- Weight: 0.83kg (excluding accessories)
- Dimensions: 310mm(L) × 50mm(W) × 50mm(H) (Full extension length)
- Piston rod diameter: 12mm
- Max theoretical thrust: 804N @ 1.0MPa
- Lubrication: Pre-lubricated (Oil-free operation possible)
High-precision industrial cylinder featuring chrome-plated piston rod and aluminum alloy barrel for corrosion resistance. The SI32 series offers smooth operation with 0.1mm/s minimum speed capability. Includes magnetic field detectability (FA suffix indicates built-in magnet for sensor mounting). Sealed against 10μm+ particulate contamination.
- Plastic injection molding machine ejectors
- Automated assembly line positioning
- Packaging machine clamping mechanisms
- CNC machine tool fixture actuation
- Textile machinery tension control
Installation note:
Maintain 0.5-1mm clearance between cylinder and guide rails. For vertical mounting,
use locking nuts on piston rod threads. Lubricate every 2,000km of cumulative stroke
movement with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | SI32X110FA |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 110mm |
