Airtac SI32 Standard Air Cylinder SI32X120
2. Piston features dual Y-shaped bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Corrosion-resistant tie rods with reinforced crisscross tubing structure;
4. Smooth cylinder operation with adjustable cushioning;
5. Multiple cylinder specifications and optional mounting accessories available for customized configurations.
Category: Standard Cylinders, Brand: AIRTAC, Series: SI32
AirTAC SI32X120 Standard Cylinder Technical Specifications
- Model: SI32X120
- Bore size: 32 mm
- Stroke: 120 mm
- Operating pressure: 0.15-1.0 MPa
- Medium: Dry air (Lubricated operation requires ISO VG32 oil)
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting types: Basic type (MF1), Foot mounting (MP2), Front flange (MP4), Rear flange (MP5)
- Port size: 1/4" NPT (M5 optional)
- Piston rod thread: M16×1.5
- Tube material: Aluminum alloy with hard anodized surface
- Seal material: NBR/PU combination
- Weight: 0.85 kg (excluding accessories)
- Dimensions: 170mm(L) × 76mm(W) × 76mm(H) (Minimum extended length)
- Max theoretical thrust: 256N @0.63MPa
- Speed range: 50-750 mm/s
- Protection class: IP54 (standard), IP67 (optional wiper upgrade)
The SI32X120 medium-duty cylinder features double-acting operation with progressive cushioning control, optimized for high cycle frequency applications. Its hard-coated barrel surface provides exceptional wear resistance, while the dual-seal design (NBR for static seals, PU for dynamic seals) ensures leak-free operation even in contaminated environments. The cylinder accepts multiple mounting configurations through standardized ISO 15552 mounting interfaces.
- Carton sealing machinery - case erectors
- Automated assembly line part transfer units
- Plastic injection molding ejector systems
- Conveyor gate actuators
- Automotive component testing jigs
Installation note:
For vertical mounting applications exceeding 0.5 m/s piston speed, install an external guide mechanism.
Lubricate through air supply (Oil mist 1-2 drops/m³) if using non-lubricated air.
Maintain 5mm minimum clearance around cylinder body for heat dissipation.
| Property | Property Value |
|---|---|
| sku | SI32X120 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 120mm |
