Airtac SI50 Standard Cylinder SI50X1000TC
2. Piston features a durable Y-type axial seal with self-compensating function, providing extended service life and low friction resistance
3. Aluminum tube with crisscross reinforcement design and anodized tie rods for enhanced corrosion resistance
4. Adjustable cushioning for smooth operation
5. Multiple configurations available with comprehensive cylinder variants and mounting accessories for flexible system integration
Category: Standard Cylinders | Brand: AirTAC | Series: SI50
AirTAC SI50X1000TC Standard Cylinder Specifications
- Model: SI50X1000TC
- Type: ISO 6432 compliant double-acting cylinder
- Bore size: Ø50 mm
- Stroke: 1000 mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–1000 mm/s
- Cushioning: Adjustable air cushion (both ends)
- Port size: G1/4 (NPT1/4 optional)
- Rod end type: Male thread M16×1.5
- Seal material: NBR/PU (standard), FKM (high temp option)
- Ambient temperature: -20℃ to 80℃
- Weight: 12.3 kg (with standard accessories)
- Dimensions: 1120mm(L) × 60mm(W) × 60mm(H)
- Rod diameter: Ø20 mm
- Magnet type: Built-in NdFeB (D-M9 connector)
- Protection rating: IP54 (standard), IP67 (optional)
High-precision long-stroke cylinder with hardened anodized aluminum barrel, designed for heavy-duty industrial applications requiring extended linear motion. Features dual anti-rotation guide slots and reinforced rod bearing for enhanced lateral load capacity (max 15% of thrust). Requires 40μm filtered lubricated air (ISO 8573-1 class 4).
- Automotive assembly line positioning systems
- Sheet metal stamping machine actuators
- Plastic injection molding ejectors
- Warehouse vertical lift mechanisms
- Steel mill material handling equipment
Installation note:
Requires horizontal mounting brackets every 800mm for full-stroke operation.
Use rod support guides when stroke/rod diameter ratio exceeds 40:1.
Lubricate through air supply (ISO VG32 recommended) during initial 100 cycles.
| Property | Property Value |
|---|---|
| sku | SI50X1000TC |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
