Airtac SI80 Standard Air Cylinder SI80X1000
2. V-ring guided Y-shaped piston seal with buffering capability, extended service life, and low friction characteristics;
3. Aluminum alloy tube with cruciform reinforcement & anti-corrosion treated tie rods for superior durability;
4. Adjustable cushioning system for smooth piston deceleration;
5. Multiple specifications and mounting accessories available for flexible configuration options.
Category: Standard Cylinders | Brand: AIRTAC | Series: SI80
AirTAC SI80X1000 Standard Cylinder Specifications
- Model: SI80X1000
- Bore size: 80 mm
- Stroke: 1000 mm
- Operating pressure: 0.05–0.9 MPa
- Medium temperature: -20℃ to 80℃
- Cushion type: Adjustable pneumatic cushion (both ends)
- Port size: Rc1/4 (G1/4 optional)
- Piston speed: 50–800 mm/s
- Rod thread: M20×1.5 (external)
- Mounting type: Basic type (MF1), optional flange/clevis mounts
- Seal material: NBR & polyurethane hybrid
- Weight: 19.8 kg (excluding accessories)
- Dimensions:
- Total length: ~1160 mm (stroke + end caps)
- Body diameter: 80 mm ±0.5 mm
- Mounting hole spacing: 140 mm (front) / 160 mm (rear)
- Rod end bracket: 50×50 mm square face
High-thrust double-acting cylinder engineered for heavy-duty linear motion applications. Features chrome-plated piston rod with multi-lip seals for zero-leakage operation. The extended stroke version (1000mm) incorporates reinforced guide bushings to prevent rod deflection. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Automotive production line clamping/pressing
- Steel coil handling systems
- Injection molding machine ejectors
- Paper roll positioning in printing presses
- Warehouse vertical lift mechanisms
Operational guidance:
Lubricate via built-in grease nipple (M6×1) every 500km stroke travel.
Avoid side load exceeding 200N. For vertical mounting, install rod lock
collar (optional AN80 accessory) to prevent unintended descent.
| Property | Property Value |
|---|---|
| sku | SI80X1000 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | <1000mm> |
