Airtac SI80 Standard Air Cylinder SI80X1000SFTC
2. V-ring guided Y-shaped piston seal with buffering capability, extended service life, and low friction characteristics;
3. Aluminum alloy tube with cruciform reinforcement & anti-corrosion treated tie rods for superior durability;
4. Adjustable cushioning system for smooth piston deceleration;
5. Multiple specifications and mounting accessories available for flexible configuration options.
Category: Standard Cylinders | Brand: AIRTAC | Series: SI80
AirTAC SI80X1000SFTC Standard Cylinder Specifications
- Model: SI80X1000SFTC
- Type: ISO 15552 compliant double-acting cylinder
- Bore size: 80mm (±0.1mm tolerance)
- Stroke: 1000mm (adjustable cushioning)
- Operating pressure: 0.1–0.9 MPa
- Piston rod material: Chrome-plated 45# steel (Φ20mm diameter)
- Tube material: Aluminum alloy AL6063-T5 (hard anodized)
- Seal material: Nitrile rubber (NBR) standard, optional Polyurethane (PU)
- Mounting type: SFTC (double clevis with foot-mounted bracket)
- Port size: G3/8 (M14×1.5 thread optional)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Max theoretical thrust: 4530N @0.63MPa
- Weight: 12.8kg (excluding accessories)
- Dimensions: 1148mm(L) × 200mm(W) × 85mm(H) (fully extended)
- Rod rotation: ±5° maximum allowable
- ISO speed range: 50–800mm/s
- Protection rating: IP65 (standard wipers)
High-precision industrial cylinder optimized for heavy-duty linear motion applications requiring extended stroke stability. Features triple sealing system (rod seal, buffer seal, and wiper) with wear-resistant guide band. The SFTC mounting configuration provides enhanced lateral load capacity for long-stroke operations.
- Automotive assembly line clamping fixtures
- Plastic injection molding machine ejectors
- Steel coil handling systems
- Paper converting machinery
- Large-scale CNC positioning tables
Installation guidelines:
Requires rigid mounting surface with flatness ≤0.1mm/m. For vertical installations,
use rod-end support when stroke/piston rod length ratio exceeds 20:1. Lubricate with
ISO VG32 hydraulic oil (non-detergent) during maintenance. Maximum side load: 15% of
theoretical thrust. Recommend replacing seals after 5,000km cumulative travel.
| Property | Property Value |
|---|---|
| sku | SI80X1000SFTC |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | <1000mm> |
