Airtac SI80 Standard Air Cylinder SI80X100FB
2. V-ring guided Y-shaped piston seal with buffering capability, extended service life, and low friction characteristics;
3. Aluminum alloy tube with cruciform reinforcement & anti-corrosion treated tie rods for superior durability;
4. Adjustable cushioning system for smooth piston deceleration;
5. Multiple specifications and mounting accessories available for flexible configuration options.
Category: Standard Cylinders | Brand: AIRTAC | Series: SI80
AirTAC SI80X100FB Standard Cylinder Specifications
- Model: SI80X100FB
- Bore size: 80 mm
- Stroke: 100 mm
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable air cushion (both ends)
- Port size: G1/4 (M10x1.0 optional)
- Mounting type: Front flange (FB) with mounting holes
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Weight: 5.2 kg ±3%
- Dimensions: 200mm(L) × 90mm(W) × 90mm(H)
- Rod end type: External thread M20x1.5
- Maximum speed: 500 mm/s
- Protection rating: IP54 (standard)
High-load industrial cylinder with optimized air consumption, featuring double-acting operation and precision-machined guide bearings. The hardened piston rod and corrosion-resistant construction ensure reliable performance in harsh environments. Requires 40μm filtered air with ISO VG32 hydraulic oil mist lubrication (optional oil-free operation).
- Die casting machine ejection systems
- Automotive assembly line clamping devices
- Palletizing robot end-effectors
- Plastic injection molding machine gates
- Heavy-duty conveyor diverters
Installation note:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use locknut (M20x1.5) to prevent unscrewing.
Lubricate through air port weekly in high-cycle applications (>500,000 cycles/month).
| Property | Property Value |
|---|---|
| sku | SI80X100FB |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
