Airtac SI80 Standard Air Cylinder SI80X100S
$113.28
Regular price
$120.78
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SI80X100S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO15552 (formerly ISO6431) Standard Cylinder
2. V-ring guided Y-shaped piston seal with buffering capability, extended service life, and low friction characteristics;
3. Aluminum alloy tube with cruciform reinforcement & anti-corrosion treated tie rods for superior durability;
4. Adjustable cushioning system for smooth piston deceleration;
5. Multiple specifications and mounting accessories available for flexible configuration options.
Category: Standard Cylinders | Brand: AIRTAC | Series: SI80
Operational guidance:
Lubricate with ISO VG32 hydraulic oil through built-in lubricator.
Maintain 5-10μm filtered air supply. Avoid side loads exceeding 30N.
For vertical mounting, use MY-series brackets to prevent piston drift.
2. V-ring guided Y-shaped piston seal with buffering capability, extended service life, and low friction characteristics;
3. Aluminum alloy tube with cruciform reinforcement & anti-corrosion treated tie rods for superior durability;
4. Adjustable cushioning system for smooth piston deceleration;
5. Multiple specifications and mounting accessories available for flexible configuration options.
Category: Standard Cylinders | Brand: AIRTAC | Series: SI80
AirTAC SI80X100S Standard Cylinder Technical Specifications
- Model: SI80X100S
- Type: ISO 15552 compliant double-acting pneumatic cylinder
- Bore size: 80 mm
- Stroke: 100 mm (±0.5mm tolerance)
- Operating pressure: 0.05-0.9 MPa
- Cushioning: Adjustable air cushion (both ends)
- Port size: G3/8 (ISO 228-1 standard)
- Piston rod thread: M20×1.5 (external)
- Mounting options: Basic (no mount), MF (front flange), MP (rear pivot), MY (axial foot)
- Operating temperature: -20℃ to 80℃
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: SUS304 stainless steel (chrome-plated)
- End caps: Aluminum alloy
- Seals: NBR (standard), optional FKM for high-temp (up to 150℃)
- Weight: 2.8 kg (without accessories)
- Dimensions:
- Extended length: 235 mm (stroke 100 + 135mm base)
- Retracted length: 135 mm
- Width (mounting face): 95 mm
- Height (including rod): 128 mm
- Rod end: Female thread + hex nut (M20×1.5)
- ISO mounting pattern: 40×40 mm (per ISO 15552)
High-precision industrial cylinder with dual piston guide design for minimal lateral deflection. Features wear-resistant chromium-plated rod and corrosion-resistant construction. Optional magnetic piston version (SI80X100S-M9) for position sensing. Maximum theoretical thrust: 4527N at 0.7MPa (push side).
Industrial Applications:
- Automated assembly line clamping mechanisms
- Plastic injection molding machine ejectors
- Material handling conveyor diverters
- Die casting machine core pull systems
- Automotive welding fixture positioning
Operational guidance:
Lubricate with ISO VG32 hydraulic oil through built-in lubricator.
Maintain 5-10μm filtered air supply. Avoid side loads exceeding 30N.
For vertical mounting, use MY-series brackets to prevent piston drift.
Service life:
≥3,000km travel distance (NBR seals) under standard conditions.
Recommend rod wiper replacement every 1 million cycles in high-contamination environments.
| Property | Property Value |
|---|---|
| sku | SI80X100S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
