Airtac SI80 Standard Air Cylinder SI80X100SCB
2. V-ring guided Y-shaped piston seal with buffering capability, extended service life, and low friction characteristics;
3. Aluminum alloy tube with cruciform reinforcement & anti-corrosion treated tie rods for superior durability;
4. Adjustable cushioning system for smooth piston deceleration;
5. Multiple specifications and mounting accessories available for flexible configuration options.
Category: Standard Cylinders | Brand: AIRTAC | Series: SI80
AirTAC SI80X100SCB Standard Cylinder Specifications
- Model: SI80X100SCB
- Type: ISO 15552 standard cylinder (double-acting)
- Bore size: 80mm
- Stroke: 100mm
- Mounting style: Basic type (multiple options available: front flange, rear flange, foot-mounted)
- Port size: G1/2 (ISO 228 standard)
- Operating pressure: 0.15–0.9 MPa
- Cushioning type: Adjustable air cushion at both ends
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- End cover material: Cast aluminum (hard anodized)
- Seal material: NBR/PU compound seals
- Operating temperature: -20℃ to 80℃
- Weight: ~3.8kg (excluding accessories)
- Dimensions (L×W×H): 320mm × 80mm × 80mm (stroke-dependent length)
- Rod thread: M20×1.5 (standard)
- Protection class: IP65 (standard), optional IP67
- Max theoretical thrust: 4523N @0.63MPa
- Max speed: 500-800mm/s (cushioned)
High-precision industrial cylinder featuring wear-resistant chromium plating and optimized flow path design. The reinforced aluminum construction provides 30% better impact resistance compared to standard models. Includes magnetic piston for position sensing compatibility and auto-lubrication grooves for reduced maintenance. Requires ISO 8573-1 air quality class 3-4-3.
- Automated production line material handling
- Press machine clamping mechanisms
- Packaging equipment positioning systems
- Automotive welding fixture actuation
- Plastic injection molding ejectors
Installation note:
Apply lubricant (ISO VG32) to rod before initial operation.
For horizontal mounting, use additional support brackets when stroke exceeds 500mm.
Magnetic switch installation requires 2mm gap adjustment with feeler gauge.
- SI-MD20 magnetic sensor kit
- SI-AS80 auto-swivel base
- SI-RK80 rod lock kit
- Heat-resistant seals (up to 120℃)
| Property | Property Value |
|---|---|
| sku | SI80X100SCB |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
