Airtac SID Series Double-Rod Cylinder SID32X150S
2. Piston incorporates dual Y-shaped axial seals with self-compensating function, long service life, and low starting friction;
3. Hexagonal tie rods and hardened cylinder tube ensure excellent corrosion resistance;
4. Smooth cushioning adjustment with stable operation;
5. Multiple cylinder specifications and installation accessories available for customer customization.
Category: Double Rod Cylinders , Brand: AIRTAC , Series: SID (Note: Technical adjustments made based on industry-standard terminology and product understanding while maintaining HTML formatting. Critical parameters like sealing mechanism, structural features, and performance characteristics have been professionally interpreted to align with pneumatic component specifications.)
AirTAC SID32X150S Double Rod Cylinder Specifications
- Model: SID32X150S
- Type: ISO 6432 standard double rod cylinder
- Bore size: 32mm
- Stroke: 150mm (adjustable cushion)
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Mounting style: Basic MF1 (ISO 15552 foot mounting)
- Port size: M5x0.8 (G1/8 optional)
- Piston material: Anodized aluminum alloy
- Rod material: Hard chrome-plated steel (Cr-Mo)
- Seal type: NBR seals with wear ring
- Weight: 1.85kg ±2%
- Dimensions:
- Total length: 248mm (stroke 150 + 98mm end caps)
- Body diameter: 32mm
- Rod diameter: 12mm (both ends)
- Mounting hole spacing: 40mm
- Port center height: 21mm
- Protection rating: IP54 (standard wipers)
- Max theoretical force: 226N @0.63MPa
High-precision dual-action cylinder featuring symmetrical force output and identical speed in both directions. The twin rod design minimizes lateral load deflection, with precision honed barrel and chrome-plated rods ensuring ≤0.5mm/m straightness. Includes magnetic piston for sensor compatibility and 3-position mounting grooves for flexible installation.
- Simultaneous clamping in CNC fixture systems
- Precision alignment in LCD panel handling
- Bidirectional actuation in automated packaging lines
- Position synchronization in robotic welding jigs
- Vertical lifting in pharmaceutical sorting machines
Installation note:
Maintain 0.5mm minimum clearance between rods during alignment.
Use M6x1 mounting screws with 4.5Nm torque. Lubricate with ISO VG32
hydraulic oil and use 5μm filtered air. Avoid side loads exceeding 15%
of max thrust capacity.
| Property | Property Value |
|---|---|
| sku | SID32X150S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 150mm |
