Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-75S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
1. ISO15552 (formerly ISO6431) compliant standard cylinder design;
2. Piston utilizes dual Y-shaped bidirectional seals with self-compensating functionality, delivering extended service life and low dynamic friction;
3. Hexagonal tie rod configuration enhances structural stability with superior corrosion resistance;
4. Optimized cylinder structure ensures smooth stroke operation;
5. Multiple cylinder specifications and mounting accessories available for customized applications.
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ100
AirTAC SIJ100X100-75S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ100X100-75S
- Type: Double rod compact cylinder with adjustable stroke
- Bore size: Ø100mm
- Stroke: 100mm (Max adjustable range ±5mm)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (front/rear)
- Mounting style: Basic type (optional flange/bracket accessories)
- Piston rod material: Hard chrome-plated carbon steel
- Seal material: NBR + PU hybrid seals
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubricated (Use ISO VG32 hydraulic oil if re-lubing)
- Port size: PT1/2 (G1/2 optional)
- Weight: 8.7kg (bare cylinder)
- Dimensions:
- Length: 364mm (min extended length)
- Width: 136mm (mounting base width)
- Height: 136mm (including both rod ends)
Heavy-duty dual rod cylinder featuring micrometer-style stroke adjustment (±5mm) through rotating end caps. Twin rod design eliminates lateral torque for precise linear motion, with integrated locknuts for position retention. Mirror-finished rods (Ra≤0.4μm) ensure consistent sealing performance. Includes built-in magnetic slot for sensor mounting (PNP/NPN compatible).
- Precision press tool alignment systems
- Automated welding positioners
- Paper converting machinery grippers
- Glass tempering oven door actuators
- Lithium battery stacking mechanisms
Installation tip:
For vertical mounting, use anti-vibration washers on both rods.
Adjust cushion screws 1/4 turn at a time during commissioning.
Maximum side load capacity: 450N at mid-stroke.
| Property | Property Value |
|---|---|
| sku | SIJ100X100-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
