Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X1000-10S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
1. ISO15552 (formerly ISO6431) compliant standard cylinder design;
2. Piston utilizes dual Y-shaped bidirectional seals with self-compensating functionality, delivering extended service life and low dynamic friction;
3. Hexagonal tie rod configuration enhances structural stability with superior corrosion resistance;
4. Optimized cylinder structure ensures smooth stroke operation;
5. Multiple cylinder specifications and mounting accessories available for customized applications.
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ100
AirTAC SIJ100X1000-10S Double Rod Adjustable Cylinder Specifications
- Model: SIJ100X1000-10S
- Type: Double rod adjustable stroke cylinder (ISO 6432 compliant)
- Bore size: Ø100 mm
- Stroke length: 1000 mm (adjustable via mechanical stops)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting: Front flange (ISO 15552 standard)
- Port size: G1/2 (BSPP thread)
- Sensor type: Built-in magnet for magnetic sensor (Reed switch compatible)
- Material:
- Cylinder tube: Aluminum alloy with hard anodized surface
- Piston rod: Chrome-plated steel (Cr-Mo steel base)
- Seals: NBR (Nitrile rubber)
- Weight: 16.8 kg (including mounting brackets)
- Dimensions:
- Total length: 1160 mm (stroke + end caps)
- Body width: 160 mm (flange to flange)
- Height: 160 mm (including rod guides)
Heavy-duty double rod cylinder designed for precision linear motion control in industrial automation. Features dual-axis stabilization for reduced lateral deflection during long-stroke operations. The adjustable mechanical stops enable precise stroke customization (±2mm adjustment resolution). Corrosion-resistant construction with IP67 protection rating ensures reliability in harsh environments.
- CNC machine tool clamping systems
- Automated conveyor belt positioning
- Automotive welding fixture actuation
- Packaging machine pusher mechanisms
- Plastic injection molding ejectors
Installation notes:
- Align within 0.2mm/m perpendicularity tolerance
- Use M12x1.5 mounting bolts (grade 8.8 or higher)
- Lubricate with ISO VG32 hydraulic oil (non-detergent)
- Maintain 50mm clearance for rod extension
| Property | Property Value |
|---|---|
| sku | SIJ100X1000-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
