Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X1000-50
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
1. ISO15552 (formerly ISO6431) compliant standard cylinder design;
2. Piston utilizes dual Y-shaped bidirectional seals with self-compensating functionality, delivering extended service life and low dynamic friction;
3. Hexagonal tie rod configuration enhances structural stability with superior corrosion resistance;
4. Optimized cylinder structure ensures smooth stroke operation;
5. Multiple cylinder specifications and mounting accessories available for customized applications.
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ100
AirTAC SIJ100X1000-50 Double Rod Adjustable Cylinder Specifications
- Model: SIJ100X1000-50
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø100 mm
- Stroke: 1000 mm (adjustable)
- Rod diameter: Ø25 mm (both rods)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Mounting type: Basic type (no built-in mounts)
- Port size: G1/2
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50-800 mm/s
- Weight: 25.8 kg (dry)
- Dimensions:
- Extended length: 1440 mm
- Body diameter: Ø116 mm
- Rod center distance: 96 mm
- Stroke adjustment range: ±5mm from nominal
- Seal material: Polyurethane (standard)/NBR (optional)
- Protection class: IP65 (DIN standard)
High-rigidity dual piston rod cylinder with precision stroke adjustment capability, featuring chromium-plated piston rods and aluminum alloy end caps. The 50-series suffix indicates integrated stroke adjustment screws with locknuts for fine position control. Requires 40μm filtered air and regular lubrication (ISO VG32 recommended).
- Press machine ejection systems
- Large-format CNC router positioning
- Automotive welding fixture clamping
- Steel coil handling equipment
- Paper roll tensioning mechanisms
Installation tip:
Use rigid mounting brackets spaced at ≤500mm intervals for full-stroke
applications. Allow 150mm front clearance for stroke adjustment tools.
Critical note:
Maximum side load capacity 320N. For lateral force applications exceeding
15% of axial force, specify guide rail kits (GRK-100A).
| Property | Property Value |
|---|---|
| sku | SIJ100X1000-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
