Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X1000-75S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
1. ISO15552 (formerly ISO6431) compliant standard cylinder design;
2. Piston utilizes dual Y-shaped bidirectional seals with self-compensating functionality, delivering extended service life and low dynamic friction;
3. Hexagonal tie rod configuration enhances structural stability with superior corrosion resistance;
4. Optimized cylinder structure ensures smooth stroke operation;
5. Multiple cylinder specifications and mounting accessories available for customized applications.
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ100
AirTAC SIJ100X1000-75S Double Rod Adjustable Cylinder Specifications
- Model: SIJ100X1000-75S
- Type: Double rod, adjustable stroke cylinder
- Bore size: Ø100mm
- Stroke: 1000mm (adjustable)
- Rod diameter: Ø25mm (both rods)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffers (both ends)
- Mounting style: 75S series - basic front flange with side mounting holes
- Port size: G3/8
- Weight: Approximately 28.5kg (dry, without accessories)
- Dimensions: 1330mm(L) × 140mm(W) × 140mm(H) (full extension)
- Material: Aluminum barrel, chrome-plated piston rod
- Seal type: NBR seals standard (FKM available for high temp)
- Protection rating: IP54 (standard wipers)
- Max theoretical force: 785N @ 0.7MPa
High-rigidity double rod cylinder designed for precision alignment in long-stroke applications. Features symmetrical force transmission and anti-rotation stability, with wear-resistant chromium rods and dual cushion adjustment. Requires 5μm filtered air with proper lubrication (ISO VG32 recommended).
- Large-format CNC machine tool clamping systems
- Automotive assembly line positioning gates
- Glass panel handling robots
- Heavy-duty material transfer elevators
- Packaging line alignment guides
Installation note:
Ensure proper alignment of dual rods using alignment jigs during mounting.
Maximum allowable lateral load: 300N. Lubricate rods weekly in high-cycle
applications (>500 cycles/day). Stroke adjustment requires 15mm minimum
buffer overlap.
| Property | Property Value |
|---|---|
| sku | SIJ100X1000-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
