Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X110-50S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
1. ISO15552 (formerly ISO6431) compliant standard cylinder design;
2. Piston utilizes dual Y-shaped bidirectional seals with self-compensating functionality, delivering extended service life and low dynamic friction;
3. Hexagonal tie rod configuration enhances structural stability with superior corrosion resistance;
4. Optimized cylinder structure ensures smooth stroke operation;
5. Multiple cylinder specifications and mounting accessories available for customized applications.
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ100
AirTAC SIJ100X110-50S Dual-Axis Adjustable Cylinder Specifications
- Model: SIJ100X110-50S
- Type: Dual-axis adjustable stroke compact cylinder
- Bore size: Ø100mm
- Stroke: 110mm (adjustable via mechanical stopper)
- Rod diameter: Ø25mm (both axes)
- Operating pressure: 0.1–1.0 MPa
- Cushioning: Adjustable pneumatic cushion
- Port size: PT1/2 (G1/2 optional)
- Mounting type: Basic non-magnetic switch model
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (standard), optional FKM
- Temperature range: -10℃ to 80℃
- Weight: 5.8kg ±2%
- Dimensions: 286mm (Length) × 160mm (Width) × 160mm (Height) (including rods at neutral position)
- Stroke tolerance: ±2.0mm
- Protection rating: IP54 (standard), IP67 optional
High-precision dual-axis cylinder with synchronized rod movement and adjustable mechanical stroke limiters. Features twin piston rods for enhanced moment resistance and anti-rotation stability. The through-hole design allows direct mounting of sensors or accessories. Compatible with AutoSwitch magnetic sensors (sold separately).
- Precision alignment in semiconductor wafer handling
- Parallel gripper mechanisms for robotic arms
- Vertical lifting platforms in assembly lines
- Position locking in CNC fixture systems
- Balanced force applications in glass manufacturing
Installation note:
Lubricate with ISO VG32 turbine oil before initial use.
Maintain 0.3mm minimum clearance between stoppers and rod ends.
For vertical installations, use counterbalance valves (not included).
- Max side load capacity: 1,500N at rod extension
- Repeat positioning accuracy: ±0.5mm
- Max speed: 800mm/s (cushioned)
- Air consumption: 12.9L per cycle (at 0.5MPa)
| Property | Property Value |
|---|---|
| sku | SIJ100X110-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
