Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X100-40S
2. Piston features dual Y-shaped bidirectional seals with dust-proof capability, offering extended service life and low frictional resistance;
3. Cylinder tube with triple tie-rod structure and cross-shaped design ensures excellent corrosion resistance;
4. Adjustable cushioning for smooth operation;
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders, Brand: Airtac, Series: SIJ125 （Note: The translation incorporates technical terminology adjustments to align with industry standards while retaining HTML line breaks. Critical clarifications include "triple tie-rod" for structural integrity and "adjustable cushioning" for precise motion control, reflecting the product's core features.）
AirTAC SIJ125X100-40S Dual Rod Adjustable Cylinder Specifications
- Model: SIJ125X100-40S
- Type: Double rod, adjustable stroke pneumatic cylinder
- Bore size: Ø125mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: G1/2 (ISO standard)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Standard foot and front flange (ISO 15552 compliant)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Weight: 5.8 kg ±2%
- Dimensions: 300mm(L) × 160mm(W) × 160mm(H)
- Rod diameter: Ø40mm (dual rods)
- Rod thread: M20×1.5 (both ends)
- Max lateral load: 850N
- ISO standard: 15552 (formerly ISO 6431)
High-rigidity dual rod cylinder with precision alignment capability, featuring twin chrome-plated guide rods for exceptional moment resistance. The symmetrical design eliminates rotational torque during operation, making it ideal for precision fixturing applications. Includes built-in stroke adjustment mechanism with ±5mm fine-tuning capability.
- Automated welding positioners requiring anti-rotation stability
- Press brake tooling alignment systems
- Plastic injection molding machine ejectors
- Heavy-duty material clamping devices
- Precision glass cutting equipment
Installation note:
Maintain parallel alignment within 0.2mm/m during mounting. Use flexible couplings
when connecting to driven components. Lubricate rods weekly with ISO VG32 hydraulic oil
in high-cycle applications (>500 cycles/minute).
| Property | Property Value |
|---|---|
| sku | SIJ125X100-40S |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
