Airtac SIJ125 Double Rod Adjustable Cylinder SIJ125X1000-40S
2. Piston features dual Y-shaped bidirectional seals with dust-proof capability, offering extended service life and low frictional resistance;
3. Cylinder tube with triple tie-rod structure and cross-shaped design ensures excellent corrosion resistance;
4. Adjustable cushioning for smooth operation;
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders, Brand: Airtac, Series: SIJ125 （Note: The translation incorporates technical terminology adjustments to align with industry standards while retaining HTML line breaks. Critical clarifications include "triple tie-rod" for structural integrity and "adjustable cushioning" for precise motion control, reflecting the product's core features.）
AirTAC SIJ125X1000-40S Dual-Axis Adjustable Cylinder Specifications
- Model: SIJ125X1000-40S
- Type: Dual-axis adjustable ISO cylinder with slide guide
- Bore size: 125mm
- Stroke: 1000mm (customizable up to 2000mm)
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -10℃ to 70℃
- Cushioning: Adjustable air cushion at both ends
- Mounting type: Front flange base (40S series)
- Port size: G1/2 (NPT1/2 optional)
- Rod material: Hard chrome-plated carbon steel
- Tube material: Aluminum alloy with hard anodized finish
- Seal material: NBR/PU (standard), optional FKM
- Weight: 18.6kg (excluding accessories)
- Dimensions: 1360mm(L) × 162mm(W) × 142mm(H)
- Piston speed: 50–800mm/s
- Repeat accuracy: ±0.5mm
- Protection rating: IP54 (standard), IP67 optional
Heavy-duty dual-axis cylinder designed for precision linear motion control in high-moment applications. Features twin piston rods (Ø25mm each) with integrated slide guides for enhanced lateral load capacity (max 850N·m). Includes stroke adjustment mechanism with mechanical locknuts and position sensor slots. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Automated welding positioners in automotive assembly
- Paper roll handling systems
- Large-format CNC router Z-axis control
- Solar panel cleaning robot articulation
- Heavy conveyor gate actuators
Installation note:
Requires rigid mounting surface with flatness ≤0.2mm/m. Lubricate guide rails with
EP2 grease during maintenance. Avoid side load exceeding 30% of maximum capacity.
| Property | Property Value |
|---|---|
| sku | SIJ125X1000-40S |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | <1000mm> |
