Airtac SIJ160 Double Rod Adjustable Cylinder SIJ160X100-40
1. Compliant with ISO15552 (formerly ISO6431) standard cylinder specifications;
2. Piston sealing system employs dual Y-type bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Features corrosion-resistant chromium-plated piston rod and cross-shaped cylinder tube structure;
4. Ensures smooth and stable cylinder operation;
5. Offers multiple cylinder specifications and compatible mounting accessories for flexible customer configurations.
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ160
AirTAC SIJ160X100-40 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ160X100-40
- Type: Double rod adjustable stroke cylinder
- Bore size: 160mm
- Stroke: 100mm (±5mm adjustable)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting type: Front flange MF1 (ISO 15552 standard)
- Port size: PT1/2 (G1/2 optional)
- Piston speed: 50-800 mm/s
- Ambient temperature: -20℃ to 80℃
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated stainless steel (SUS304)
- Seals: NBR (nitrile rubber) for standard use
- Weight: 12.5kg (excluding accessories)
- Dimensions:
- Length: 310mm (basic length) + stroke
- Width: 185mm (flange mounting surface)
- Height: 180mm (including rod ends)
- Rod thread: M20×1.5 (both ends)
- Lubrication: Pre-lubricated (relubrication interval: 3,000km)
High-precision dual rod cylinder with micro-adjustment capability (±5mm stroke adjustment) through integrated locknuts. Features corrosion-resistant construction with IP67 protection rating, suitable for harsh environments. The double rod design provides balanced force distribution and enhanced stability during reciprocating motion.
- Precision press machine tooling
- Automated material handling systems
- Automotive assembly line positioning
- Plastic injection molding ejectors
- Heavy-duty clamping fixtures
Installation tips:
Maintain parallel alignment of dual rods during installation. Use alignment couplers (not included) for synchronized motion applications. Recommended air filtration: 5μm with auto-drain. Allow 0.5-1mm thermal expansion clearance at mounting points.
- Loosen both locknuts using 24mm wrench
- Rotate adjustment screw (5mm hex key) - 1 full rotation = 1.5mm stroke change
- Re-tighten locknuts to 35N·m torque
| Property | Property Value |
|---|---|
| sku | SIJ160X100-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | 160mm |
| Stroke | 100mm |
