Airtac SIJ160 Double Rod Adjustable Cylinder SIJ160X100-50S
1. Compliant with ISO15552 (formerly ISO6431) standard cylinder specifications;
2. Piston sealing system employs dual Y-type bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Features corrosion-resistant chromium-plated piston rod and cross-shaped cylinder tube structure;
4. Ensures smooth and stable cylinder operation;
5. Offers multiple cylinder specifications and compatible mounting accessories for flexible customer configurations.
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ160
AirTAC SIJ160X100-50S Twin Axis Adjustable Cylinder Specifications
- Model: SIJ160X100-50S
- Type: Double rod, adjustable stroke twin-axis cylinder
- Bore size: Ø16mm (160 series)
- Stroke: 100mm (standard), adjustable ±5mm
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Rubber buffer + adjustable stopper
- Port size: M5x0.8 (G1/8 equivalent)
- Rod diameter: Ø12mm (chromed steel)
- Adjustment range: 90-110mm total stroke
- Body material: Aluminum alloy (anodized)
- Seal material: NBR + Polyurethane
- Mounting style: Front flange (standard), optional side mounts
- Weight: 1.85kg (with standard accessories)
- Dimensions: 200mm(L) × 82mm(W) × 76mm(H) (at mid-stroke)
Precision twin-rod cylinder featuring dual-axis guidance for enhanced moment resistance. The chrome-plated guide rods and adjustable mechanical stoppers enable micron-level positioning repeatability (±0.1mm). Includes integrated shock absorbers and dust-resistant wiper seals. Requires ISO 8573-1:2010 Class 3 compressed air.
- Precision alignment in semiconductor wafer handling
- Vertical lift mechanisms for CNC tool changers
- Parallel gripper actuation in pick-and-place systems
- Position locking in automotive welding fixtures
- Z-axis control for 3D printing platforms
Installation note:
Lubricate guide rods with ISO VG32 hydraulic oil before initial operation.
For vertical mounting, install air vents upward. Maximum side load: 15N.
| Property | Property Value |
|---|---|
| sku | SIJ160X100-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | 160mm |
| Stroke | 100mm |
