Airtac SIJ160 Double Rod Adjustable Cylinder SIJ160X100-75
$383.61
Regular price
$391.11
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SIJ160X100-75
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SIJ160 Double Axis Adjustable Cylinder
1. Compliant with ISO15552 (formerly ISO6431) standard cylinder specifications;
2. Piston sealing system employs dual Y-type bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Features corrosion-resistant chromium-plated piston rod and cross-shaped cylinder tube structure;
4. Ensures smooth and stable cylinder operation;
5. Offers multiple cylinder specifications and compatible mounting accessories for flexible customer configurations.
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ160
Installation note:
Always align cylinder axis within 0.2° of horizontal plane. Use locknuts (included)
on adjustment screws after positioning. Lubricate through AU-1 grease nipple
every 50km of travel.
Critical parameter:
Maximum allowable moment load – 85N·m (axial), 45N·m (radial).
Exceeding may cause rod bending.
1. Compliant with ISO15552 (formerly ISO6431) standard cylinder specifications;
2. Piston sealing system employs dual Y-type bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Features corrosion-resistant chromium-plated piston rod and cross-shaped cylinder tube structure;
4. Ensures smooth and stable cylinder operation;
5. Offers multiple cylinder specifications and compatible mounting accessories for flexible customer configurations.
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ160
AirTAC SIJ160X100-75 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ160X100-75
- Type: Double rod dual-axis adjustable cylinder (ISO 15552 compliant)
- Bore size: 160mm
- Stroke: 100mm ± adjustable range (±75mm via built-in mechanical stopper)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Piston speed: 50–800 mm/s (lubricated condition)
- Ambient temperature: -10℃ to 80℃
- Port size: G1/2 (BSPP thread)
- Rod material: Hard chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: High wear-resistant polyurethane (AU)
- Mounting: Standard ISO mounting foot (NF series compatible)
- Weight: 2.8kg (excluding accessories)
- Dimensions:
- Total length: 395mm (at mid-stroke)
- Body width: 180mm (including mounting flanges)
- Height: 160mm (rod axis to base)
- Rod diameter: 25mm (per rod)
- Accessories: Built-in magnet for position sensing (D-M9 connector compatible)
- Protection rating: IP54 (standard), IP67 optional
High-precision dual-axis cylinder designed for synchronized linear motion control. Features dual piston rods with micrometer-grade position repeatability (±0.2mm). The 75mm adjustable stroke mechanism enables dynamic positioning without disassembly. Anti-rotation design maintains parallel rod alignment under heavy side loads.
Typical Applications:
- Automated palletizing systems requiring synchronized grippers
- Precision glass panel handling in LCD manufacturing
- Die-casting machine core-pulling mechanisms
- Parallel lifting platforms in automotive assembly
- Pharmaceutical blister packaging alignment systems
Installation note:
Always align cylinder axis within 0.2° of horizontal plane. Use locknuts (included)
on adjustment screws after positioning. Lubricate through AU-1 grease nipple
every 50km of travel.
Critical parameter:
Maximum allowable moment load – 85N·m (axial), 45N·m (radial).
Exceeding may cause rod bending.
| Property | Property Value |
|---|---|
| sku | SIJ160X100-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | 160mm |
| Stroke | 100mm |
