Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X100-10
AirTAC SIJ200X100-10 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ200X100-10
- Type: Double rod, dual-axis adjustable cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 100mm (±1mm tolerance)
- Adjustment range: ±5° angular adjustment on both axes
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable rubber buffers at both ends
- Mounting style: Front flange (MF1) / Rear flange (MF2) optional
- Material: Aluminum alloy cylinder tube, hardened stainless steel piston rods
- Seal material: NBR seals with wear-resistant rings
- Ambient temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated (ISO VG32 recommended for maintenance)
- Weight: 2.8kg (without accessories)
- Dimensions: 200mm(L) × 60mm(W) × 60mm(H) (at mid-stroke position)
- Protection rating: IP54 (standard wiper design)
- Piston rod thread: M10×1.25 at both ends
Precision dual-axis cylinder featuring independent angular adjustment capability (±5°) through eccentric collars on both axes. The dual rod design provides enhanced rigidity against lateral forces, with chromium-plated piston rods offering corrosion resistance. Includes magnetic piston for position sensing compatibility (sensor not included).
- Precision fixture alignment in CNC machining centers
- Multi-axis positioning in semiconductor handling robots
- Conveyor gate synchronization systems
- Automated optical inspection equipment adjustments
- Packaging machine material clamping with tilt compensation
Installation notes:
- Align adjustment scales (marked at 0.5° increments) before torque application
- Maximum recommended side load: 15N at full extension
- Use locknuts (included) after angular adjustment - torque to 4.5N·m±10%
- For vertical installations, maintain ≥0.3MPa pressure to prevent seal dry-out
Maintenance cycle: Relubricate every 500km of cumulative travel or annually. Replace wiper seals every 3 million cycles in normal operating conditions.
| Property | Property Value |
|---|---|
| sku | SIJ200X100-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
