Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X100-100
$529.45
Regular price
$536.95
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SIJ200X100-100
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**SIJ200 Dual-Axis Adjustable Cylinder**
1. ISO15552 (formerly ISO6431) compliant standard cylinder design.
2. Piston sealed with dual Y-type bidirectional sealing structure, ensuring superior leak resistance, extended service life, and low friction.
3. Aluminum alloy tube with reinforced cross-rib design and black-anodized piston rod for enhanced corrosion resistance.
4. Smooth cylinder operation with minimal vibration and precise control.
5. Multiple cylinder specifications and mounting accessories available for flexible customization.
**Category:** Adjustable Cylinders
**Brand:** AIRTAC
**Series:** SIJ200
*Note: The translation optimizes technical terminology while maintaining accuracy. Key improvements include specifying "bidirectional sealing," "cross-rib design," and "black-anodized" for clarity in industrial contexts.*
Installation guidelines:
AirTAC SIJ200X100-100 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ200X100-100
- Type: Double rod, adjustable stroke cylinder
- Bore size: Ø200 mm
- Stroke: 100 mm (adjustable via stopper)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Port size: Rc1/2 (G1/2 optional)
- Cushioning: Adjustable rubber bumper + air cushion
- Mounting: Side lug (ISO 15552 standard)
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Weight: 18.5 kg ±2%
- Dimensions (L×W×H):
- Extended length: 790 mm
- Retracted length: 690 mm
- Body width: 250 mm
- Mounting height: 330 mm
- Protection rating: IP54 (standard wiper seal)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil if required)
Heavy-duty dual-axis cylinder with precision stroke adjustment mechanism, featuring twin piston rods for enhanced moment resistance and position stability. The T-slot design on mounting surface allows flexible accessory installation. Includes magnetic piston for sensor compatibility and corrosion-resistant anodized surface treatment.
Typical Applications:
- Automated material handling systems requiring dual-point positioning
- Press machine tooling with precise stroke control needs
- Automotive assembly line fixture clamping mechanisms
- Heavy load transfer applications in foundry equipment
- Packaging machinery requiring anti-rotation stability
Installation guidelines:
- Ensure dual rods remain parallel within 0.2mm/m alignment tolerance
- Apply thread locker (medium strength) to adjustment bolts
- Limit side load to ≤15% of maximum thrust capacity
- For vertical mounting, install anti-drop safety brackets
| Property | Property Value |
|---|---|
| sku | SIJ200X100-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
