Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X100-100S
AirTAC SIJ200X100-100S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ200X100-100S
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø200mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.1–0.8 MPa
- Piston rod diameter: Ø45mm (both rods)
- Cushioning: Adjustable hydraulic shock absorber
- Mounting type: Standard MF1 flange with 16×M12 mounting holes
- Port size: G1/4 (two ports per cylinder end)
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy cylinder body, chrome-plated steel piston rods
- Seal material: Heat-resistant NBR seals
- Weight: 18.5kg (without accessories)
- Dimensions: 400mm(L) × 240mm(W) × 240mm(H)
- Protection rating: IP40 (dust protected)
Heavy-duty dual-axis cylinder with precision stroke adjustment mechanism, featuring synchronized movement control through twin piston rods. The hardened guide rods and oversized bearings enable stable linear motion under lateral loads up to 3000N. Includes built-in stroke adjustment locks with ±2mm positioning accuracy.
- Automated palletizing systems requiring synchronized clamping
- Press machine tooling with precise depth control
- Automotive assembly line positioning fixtures
- Heavy material handling equipment
- Plastic injection molding machine ejectors
Installation notes:
Requires rigid mounting surface (flatness ≤0.1mm/m). Lubricate rods weekly with ISO VG32 hydraulic oil.
For vertical installations, use counterbalance valves. Maximum side load capacity reduces by 30% at full extension.
| Property | Property Value |
|---|---|
| sku | SIJ200X100-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
