Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X100-10S
$538.75
Regular price
$546.25
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SIJ200X100-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**SIJ200 Dual-Axis Adjustable Cylinder**
1. ISO15552 (formerly ISO6431) compliant standard cylinder design.
2. Piston sealed with dual Y-type bidirectional sealing structure, ensuring superior leak resistance, extended service life, and low friction.
3. Aluminum alloy tube with reinforced cross-rib design and black-anodized piston rod for enhanced corrosion resistance.
4. Smooth cylinder operation with minimal vibration and precise control.
5. Multiple cylinder specifications and mounting accessories available for flexible customization.
**Category:** Adjustable Cylinders
**Brand:** AIRTAC
**Series:** SIJ200
*Note: The translation optimizes technical terminology while maintaining accuracy. Key improvements include specifying "bidirectional sealing," "cross-rib design," and "black-anodized" for clarity in industrial contexts.*
Installation note:
Lubricate guide rods with ISO VG32 hydraulic oil before initial use.
Ensure parallel alignment within 0.1mm/meter to prevent binding.
For vertical mounting, install with rod end downward to prevent piston drift.
AirTAC SIJ200X100-10S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ200X100-10S
- Type: Dual-axis adjustable stroke pneumatic cylinder
- Bore size: 20mm (ISO standard)
- Stroke: 100mm (mechanically adjustable)
- Rod diameter: 10mm (chrome-plated steel)
- Operating pressure: 0.1-1.0 MPa
- Port size: G1/8 (BSPP thread)
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting style: Dual through-hole base (M5x0.8 mounting screws)
- Material: Aluminum alloy body, stainless steel guide rods
- Seal type: NBR seals (oil-resistant)
- Temperature range: -20℃ to 80℃
- Weight: 1.65kg ±2%
- Dimensions: 200mm(L) × 62mm(W) × 42mm(H) (at mid-stroke)
- Rod end type: 5mm female thread (M5x0.8)
- Repeat positioning accuracy: ±0.2mm
- Max lateral load: 15N
High-precision dual-rod cylinder with mechanical stroke adjustment, featuring parallel chrome-plated guide rods for anti-rotation stability. The through-rod design allows external stroke adjustment via limit collars. Includes wear-resistant guide bushings and IP54-rated protection against particulate ingress.
Typical Applications:
- Precision fixturing/clamping in CNC tool changers
- Vertical lifting mechanisms in packaging lines
- Positioning stages for optical inspection systems
- Material handling with guided ejection
- Automated welding equipment actuators
Installation note:
Lubricate guide rods with ISO VG32 hydraulic oil before initial use.
Ensure parallel alignment within 0.1mm/meter to prevent binding.
For vertical mounting, install with rod end downward to prevent piston drift.
Adjustment procedure:
- Loosen both lock nuts on guide rods
- Slide limit collars to desired stroke position
- Retighten nuts to 1.2-1.5N·m torque
- Verify smooth operation through full travel
| Property | Property Value |
|---|---|
| sku | SIJ200X100-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
