Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X100-20
AirTAC SIJ200X100-20 Double Rod Adjustable Cylinder Specifications
- Model: SIJ200X100-20
- Type: Double rod cylinder with adjustable stroke
- Bore size: Ø200mm
- Stroke: 100mm standard (adjustable range: ±10mm via built-in stoppers)
- Rod diameter: Ø40mm (both rods)
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting styles: Front flange (MF1), rear flange (MF2), or foot mounting (MP4)
- Material: Aluminum alloy cylinder tube, hardened steel rods
- Seal type: NBR seals with wear-resistant guide rings
- Weight: 8.5kg (dry, without accessories)
- Dimensions: 340mm(L) × 250mm(W) × 250mm(H) (fully retracted)
- Port size: G1/2 (standard), optional NPT1/2 available
- Protection rating: IP40 (standard), IP67 optional with rod wipers
- Max thrust: 28,270N at 0.7MPa (calculated value)
Heavy-duty double rod cylinder engineered for precision alignment applications requiring parallel motion control. Features twin hardened chrome-plated rods for enhanced rigidity and anti-rotation stability. The 360° adjustable stroke mechanism allows micro-positioning through graduated dial indicators (±10mm range). Includes wear-resistant guide bushings for minimal play during high-moment loading.
- CNC machine tool clamping systems
- Automated pallet positioning in logistics systems
- Press tool alignment mechanisms
- Glass handling vacuum cup arrays
- Automotive welding fixture synchronization
Installation note:
Requires minimum 0.5mm/m alignment tolerance during mounting. Lubricate rods weekly with ISO VG32 hydraulic oil.
For vertical installations, use rod end supports (optional accessory SJ-FM200).
| Property | Property Value |
|---|---|
| sku | SIJ200X100-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
