Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X100-30
AirTAC SIJ200 Dual-Axis Adjustable Cylinder SIJ200X100-30 Technical Specifications
- Model: SIJ200X100-30
- Type: Dual-axis adjustable pneumatic cylinder (ISO 15552 compliant)
- Bore size: 200 mm
- Stroke: 100 mm (adjustable ±1.5° angular tolerance)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s (lubricated operation)
- Port size: G3/8 (NPT1/2 optional)
- Cushioning: Adjustable hydraulic shock absorber (5-stage)
- Rod material: Chrome-plated steel (S45C)
- Tube material: Anodized aluminum alloy (AL6063-T5)
- Seal type: NBR + PU combination seals
- Temperature range: -20℃ to 80℃
- Weight: 12.8 kg (with standard accessories)
- Dimensions: 580mm(L) × 240mm(W) × 240mm(H) (max extended length)
- Mounting: ISO 15552 standard foot & front flange (NF-8 pattern)
- Rod end: M20×1.5 female thread (alternative ends available)
- Position detection: 2x T-slot sensor grooves (8mm width)
High-precision dual-axis cylinder engineered for heavy-duty alignment applications. Features synchronized rod movement with micron-level parallelism (≤0.05mm/m deviation). Integrated oil mist lubrication ports and corrosion-resistant surface treatment enable operation in humid environments. Requires ISO VG32 hydraulic oil for optimal shock absorber performance.
- Automotive welding fixture positioning systems
- Die-casting machine core-pulling mechanisms
- Sheet metal press brake tool alignment
- Semiconductor wafer handling robots
- Heavy conveyor belt tensioning systems
Installation protocol:
Mount on machined surface with flatness ≤0.1mm/m². Always perform axis
synchronization calibration using included alignment jigs before initial
operation. Lubricate through side ports every 500km of cumulative stroke.
| Property | Property Value |
|---|---|
| sku | SIJ200X100-30 |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
