Airtac SIJ200 Double Rod Adjustable Cylinder SIJ200X100-30S
$538.75
Regular price
$546.25
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SIJ200X100-30S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**SIJ200 Dual-Axis Adjustable Cylinder**
1. ISO15552 (formerly ISO6431) compliant standard cylinder design.
2. Piston sealed with dual Y-type bidirectional sealing structure, ensuring superior leak resistance, extended service life, and low friction.
3. Aluminum alloy tube with reinforced cross-rib design and black-anodized piston rod for enhanced corrosion resistance.
4. Smooth cylinder operation with minimal vibration and precise control.
5. Multiple cylinder specifications and mounting accessories available for flexible customization.
**Category:** Adjustable Cylinders
**Brand:** AIRTAC
**Series:** SIJ200
*Note: The translation optimizes technical terminology while maintaining accuracy. Key improvements include specifying "bidirectional sealing," "cross-rib design," and "black-anodized" for clarity in industrial contexts.*
Operation note:
Always loosen locknut before stroke adjustment. Perform stroke calibration under 0.3 MPa or lower pressure.
Maximum permissible side load: 1,500 N. For vertical installations, use anti-vibration pads on mounting surface.
AirTAC SIJ200X100-30S Double Rod Adjustable Cylinder Specifications
- Model: SIJ200X100-30S
- Type: Double rod adjustable stroke cylinder (ISO 15552 compliant)
- Bore size: Ø200 mm
- Stroke: 100 mm (adjustable via external stoppers)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushioning (both ends)
- Ambient temperature: -20℃ to 80℃
- Medium temperature: 0℃ to 70℃
- Port size: G1-1/2 (NPT1-1/2 optional)
- Rod material: Chrome-plated carbon steel (S45C)
- Tube material: Aluminum alloy with hard anodized surface
- Seal material: NBR/PU combination
- Weight: 18.5 kg ±2%
- Dimensions (L×W×H):
- Extended length: 740 mm
- Retracted length: 640 mm
- Body width: 250 mm
- Mounting height: 210 mm
- Mounting types: Fixed MF1/MF2, Axis fixed, Front flange
- Lubrication: Pre-lubricated (Oil mist lubrication recommended)
High-precision industrial cylinder featuring dual external stroke adjustment screws (M30×1.5 thread) with locknuts for position fine-tuning. The 360° rotatable mounting brackets enable flexible installation in confined spaces. Equipped with wear-resistant scraper seals and magnetic piston for position feedback compatibility.
Typical Applications:
- Precision press tool positioning in automotive assembly
- Variable height adjustment in semiconductor wafer handling
- Clamping force modulation in injection molding machines
- Material feeding systems requiring stroke calibration
- Automated palletizing with variable stacking heights
Operation note:
Always loosen locknut before stroke adjustment. Perform stroke calibration under 0.3 MPa or lower pressure.
Maximum permissible side load: 1,500 N. For vertical installations, use anti-vibration pads on mounting surface.
| Property | Property Value |
|---|---|
| sku | SIJ200X100-30S |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
